4. Check the sample types that you want included in the chart record, and then
set the Day Start Hour and Period values, if required.
Sample types that can be included in the chart record are: Fire Alarm and Fire
Alarm 2, Alert/Aux. Alarm, Prealarm, Detector Level, Flow, and Temperature.
5. Press F1 (Save).
The chart record is saved as a comma separated (CSV) file to the following
folder on the USB flash drive:
_ASPIRATION\Chart\
This folder is created automatically on the flash drive. The name of the saved
file takes the format:
AAA_YYYYMMDD_HHMM_TT.csv
Where AAA is the device address, YYYYMMDD is the current date, HHMM is
the current time, and TT is a the device type identification code.
6. Press F3 (Exit) to return to the Main menu.

The Test menu

Use the Test menu to perform tests. Available tests are shown in the table below.
Note: The system automatically exits a test after 100 minutes if the test is not
ended manually.
Table 16: The Test menu
Option
Installation test
Output test
Input test
User interface test
Diagnostics [1]
[1] Selected legacy devices only.
Note: If a module is in an alarm condition, active tests cannot be exited manually
until the alarm status is cleared.
Performing an installation test
The installation test is used to test fire detection and notification.
When this test mode is active:
• General fault outputs are activated
• Fire outputs are not activated
ModuLaser Modular Aspirating Smoke Detector Installation Manual
Description
Tests fire detection and notification
Tests outputs
Tests inputs
Tests the user interface (LEDs, buttons, etc.)
Tests various diagnostics
Chapter 3: Configuration and Commissioning
49
