The configurable options for the output functionality are shown in the table below.
Table 22: Output functionality
Function
General Alarm
Alert
Prealarm
Alarm
Alarm 2
General Fault
Battery Fault
Mains Fault
Power Supply Fault
Flow Fault
Filter Blocked
Filter Removed
Laserhead Fault
Fan Fault
Cover Removed
General Warning
Disable
Test
ModuLaser Modular Aspirating Smoke Detector Installation Manual
Description
The output activates when the applicable device or devices are in
any alarm state.
The output activates when the applicable device or devices are in
Alert/Aux. Alarm state.
The output activates when the applicable device or devices are in
Prealarm state.
The output activates when the applicable device or devices are in
Fire Alarm state.
The output activates when the applicable device or devices are in
Fire Alarm 2 state.
The output deactivates when the applicable device or devices are
in any fault state, disabled, or in test mode.
This behaviour is opposite to outputs configured with any other
function.
The output activates when the applicable device or devices are in
Battery Fault state.
The output activates when the applicable device or devices are in
Mains Fault state.
The output activates when the applicable device or devices are in
Power Supply Fault state.
The output activates when the applicable device or devices are in
Flow Fault state.
The output activates when the applicable device or devices are in
Filter Blocked fault state
The output activates when the applicable device or devices are in
Filter Removed fault state.
The output activates when the applicable device or devices are in
Laserhead Fault state.
The output activates when the applicable device or devices are in
Fan Fault state.
The output activates when the applicable device or devices are in
Cover Removed fault state.
The output activates when the applicable device or devices are in
any Warning state.
The output activates when the applicable device or devices are
disabled.
The output activates when the applicable device or devices are in
any Test state.
