ORDERING INFORMATION

BILL OF MATERIALS

Table 6.
Reference Designator Description
C1, C4, C17, C18 0.1 μF ceramic capacitor, 50 V, X7R 0603
C10 0.0047 μF ceramic capacitor, 50 V, X7R 1206
C11 0.001 μF ceramic capacitor, 50 V, NP0 1206
C2 10 μF ceramic capacitor, 25 V, X5R 0805
C3, C12 1 μF ceramic capacitor, 25 V, X7R 0603
C5, C6, C7 22 μF ceramic capacitor, 25 V, X5R 0805
C8 300 pF ceramic capacitor, 50 V, C0G (NP0) 0603
C9, C16 0.1 μF ceramic capacitor, 25 V, X7R 1206
D1 Diode, ultrafast rectifier
D2 Diode, SMT ultrafast power rectifier
D3 Diode, ultrafast plastic rectifier, 1 A
P17 10-pin system demonstration platform (SDP)
P17 (alternate) WR-MM female connector
Q1 Transistor, HEXFET power MOSFET
Q2 Transistor, N-channel HEXFET power MOSFET
R1 2 Ω resistor, 1206
R10 20 Ω resistor, 0603
R11 20 kΩ resistor, 0603
R12 0.1 Ω resistor, 0603
R13, R19 10 kΩ resistor, 0603
R14 20 kΩ resistor, 1206
R15 10 Ω resistor, 1206
R16 0 Ω resistor, 0603
R18, R20 1 MΩ resistor, 0603
R2, R9, R25 1 Ω resistor, 1206
R21 3.48 kΩ resistor, 0603
R22 6.98 kΩ resistor, 0603
R23, R24 1.82 kΩ resistor, 1206
R26 20 kΩ resistor, 0603
R3 100 Ω resistor, 1206
R4, R5 30.1 kΩ resistor, 0603
R6, R17 Not installed
R7 100 Ω resistor, 0603
R8 49.9 Ω resistor, 0603
T1 Sumida 13 μH primary 1:2 transformer
U1 Isolated IGBT gate driver
User Guide
Rev. 0 | Page 17 of 18
Part Number Supplier
GRM188R71H104JA93D Murata
CC1206KRX7R9BB472 Yageo
12061A102JAT2A AVX
GRM21BR61E106KA73L Murata
GRM188R71A105KA61D Murata
GRT21BR61E226ME13L Murata
GRM1885C1H301JA01D Murata
CC1206KRX7R9BB104 Yageo
US1M-E3/61T Vishay
MURA140T3G Murata
ES1D-E3/61T Vishay
8-215079-0 TE Connectivity LTD
690367181072 Wurth Electronics
IRLML0060TRPBF Infineon
IRLML2030TRPBF Infineon
ERJ-8RQF2R0V Panasonic
P0603E20R0BBT Vishay
ERJ-3EKF2002V Panasonic
ERJ-3RSFR10V Panasonic
ERJ-3EKF1002V Panasonic
ERJ-8ENF2002V Panasonic
ERJ-8ENF10R0V Panasonic
ERJ-3GEY0R00V Panasonic
ERJ-3EKF1004V Panasonic
ERJ-8RQF1R0V Panasonic
ERJ-3EKF3481V Panasonic
ERJ-3EKF6981V Panasonic
RC1206FR-071K82L Yageo
ERJ-3GEYJ203V Panasonic
ERJ-8ENF1000V Panasonic
ERJ-3EKF3012V Panasonic
Not applicable Not applicable
ERJ-3EKF1000V Panasonic
ERJ-3EKF49R9V Panasonic
12322-T235 Sumida
ADuM4138BRWZ Analog Devices, Inc.
