  • Page 1 3D Printer User Guide Inkspire...

  • Page 2: Table Of Contents

    Table of content Introduction General Safety Information Learn More About the Zortrax Inkspire How does the Zortrax Inkspire work? What’s in the Box Main Components Zortrax 3D Printing Technology Glossary First Use Preparations Connecting the printer to a network Firmware Update...

  • Page 3: Introduction

    Due to the size and specificity, the Zortrax Inkspire is not intended for use by minors and by people with reduced manual, motor and psychomotor skills. The Manufacturer recommends providing assistance and guidance to people with disabilities and older adults who wish to operate the printer.
  • Page 4 Printing process with the Zortrax Inkspire requires using synthetic resin which in a liquid form is toxic and may cause allergic reactions. Therefore, you must protect your skin and eyes when using the printer by wearing safety gloves and glasses.
  • Page 5 All maintenance and repair work should be carried out while the device is off and unplugged. Modifications such as soldering of electronic subunits are forbidden. ©2019, Zortrax S.A. All rights reserved. All trade names, logos and trademarks mentioned in the following document are registered trademarks of Zortrax and are subject to legal protection.
  • Page 6 Safe Storage and Transport Guidance Zortrax devices must be stored between 0 and 35° C [32 - 95° F]. The storage space should be free of moisture and other extreme conditions.

  • Page 7: Learn More About The Zortrax Inkspire

    Electromagnetic Compatibility (EMC) Zortrax printer complies with Part 15 of the FCC rules. Its operation is subject to the following two conditions: this device may not cause harmful interference, and this device must accept any interference received, including interference that may cause undesired operation.

  • Page 8: How Does The Zortrax Inkspire Work

    The next step is to open the .stl file (or other) in Z-SUITE - the program created specifically for Zortrax devices. Z-SUITE prepares the model by slicing it into individual layers and saving it as a .zcodex file. Z-SUITE also allows you to choose the material type to be used for the model and to adjust the necessary print settings, such as layer thickness, layer exposure time, exposure off time or how many support structures should be generated.

  • Page 9: What's In The Box

    What’s in the Box ©2019, Zortrax S.A. All rights reserved. All trade names, logos and trademarks mentioned in the following document are registered trademarks of Zortrax and are subject to legal protection.

  • Page 10: Main Components

    Main Components 1. Left-side view ©2019, Zortrax S.A. All rights reserved. All trade names, logos and trademarks mentioned in the following document are registered trademarks of Zortrax and are subject to legal protection.
  • Page 11 2. Back view 3. Right-side view ©2019, Zortrax S.A. All rights reserved. All trade names, logos and trademarks mentioned in the following document are registered trademarks of Zortrax and are subject to legal protection.

  • Page 12: Zortrax 3D Printing Technology Glossary

    The raft increases adhesion of the print and support structures to the platform. ©2019, Zortrax S.A. All rights reserved. All trade names, logos and trademarks mentioned in the following document are registered trademarks of Zortrax and are subject to legal protection.
  • Page 13 UV light. It also helps to keep unpleasant smells of resin inside the printing chamber. ©2019, Zortrax S.A. All rights reserved. All trade names, logos and trademarks mentioned in the following document are registered trademarks of Zortrax and are subject to legal protection.
  • Page 14 The last step is to transfer the file to the printer’s storage over Wi-Fi/Ethernet cable or by using a USB flash drive. ©2019, Zortrax S.A. All rights reserved. All trade names, logos and trademarks mentioned in the following document are registered trademarks of Zortrax and are subject to legal protection.

  • Page 15: First Use Preparations

    1. Open the box and remove the upper cushioning. 2. Remove the UV cover. ©2019, Zortrax S.A. All rights reserved. All trade names, logos and trademarks mentioned in the following document are registered trademarks of Zortrax and are subject to legal protection.
  • Page 16 4. Take the printer out of the box. Do not grab the Z-axis screw when lifting the printer. ©2019, Zortrax S.A. All rights reserved. All trade names, logos and trademarks mentioned in the following document are registered trademarks of Zortrax and are subject to legal protection.
  • Page 17 Starter Kit to tighten or loosen the printer’s legs as needed. ©2019, Zortrax S.A. All rights reserved. All trade names, logos and trademarks mentioned in the following document are registered trademarks of Zortrax and are subject to legal protection.
  • Page 18 8. Clean the FEP film inside the resin tank with a cloth. ©2019, Zortrax S.A. All rights reserved. All trade names, logos and trademarks mentioned in the following document are registered trademarks of Zortrax and are subject to legal protection.
  • Page 19 10. Plug in the power cable and turn on the printer. Connect it to a network via Wi-Fi or Ethernet. Go to Settings and configure the connection using options from the menu. ©2019, Zortrax S.A. All rights reserved. All trade names, logos and trademarks mentioned in the following document are registered trademarks of Zortrax and are subject to legal protection.
  • Page 20 If so, download the file and save it on the USB drive. Plug the USB drive into the port at the front to start the installation. ©2019, Zortrax S.A. All rights reserved. All trade names, logos and trademarks mentioned in the following document are registered trademarks of Zortrax and are subject to legal protection.
  • Page 21 14. You have finished the set-up. Your device is ready to print. ©2019, Zortrax S.A. All rights reserved. All trade names, logos and trademarks mentioned in the following document are registered trademarks of Zortrax and are subject to legal protection.

  • Page 22: Connecting The Printer To A Network

    Connecting the printer to a network The Zortrax Inkspire can be connected to a local network in two ways: via Wi-Fi or an Ethernet cable. Both methods allow you to manage the printer directly from Z-SUITE and make it possible to remotely transfer .zcodex files from your computer to the printer.
  • Page 23 You can control the Ethernet connection settings in the main menu; select Settings and Ethernet. ©2019, Zortrax S.A. All rights reserved. All trade names, logos and trademarks mentioned in the following document are registered trademarks of Zortrax and are subject to legal protection.
  • Page 24 You can also add a printer manually by typing its IP address. ©2019, Zortrax S.A. All rights reserved. All trade names, logos and trademarks mentioned in the following document are registered trademarks of Zortrax and are subject to legal protection.
  • Page 25 In the 3D Printer Files tab, you can preview all .zcodex files that are stored on the printer’s USB flash drive. ©2019, Zortrax S.A. All rights reserved. All trade names, logos and trademarks mentioned in the following document are registered trademarks of Zortrax and are subject to legal protection.

  • Page 26: Firmware Update

    You can also check if there is a newer firmware version available at any point of working with the Zortrax Inkspire and update the firmware. Select Settings -> About Printer -> Check for updates.

  • Page 27: Navigating Through The Menu

    Select Print to choose a model for printing and start the printing process. The printer will display all information concerning the process on the screen. ©2019, Zortrax S.A. All rights reserved. All trade names, logos and trademarks mentioned in the following document are registered trademarks of Zortrax and are subject to legal protection.

  • Page 28: Changing The Resin

    2. Loosen the two screws that secure the resin tank (A). Next, remove the tank (B). ©2019, Zortrax S.A. All rights reserved. All trade names, logos and trademarks mentioned in the following document are registered trademarks of Zortrax and are subject to legal protection.
  • Page 29 4. Put the resin tank in the Ultrasonic Cleaner and turn on the device for about 30-60 seconds. ©2019, Zortrax S.A. All rights reserved. All trade names, logos and trademarks mentioned in the following document are registered trademarks of Zortrax and are subject to legal protection.
  • Page 30 6. Clean the LCD screen. Once the resin tank is dry, install it back in the printer (A) and secure it with the screws (B). ©2019, Zortrax S.A. All rights reserved. All trade names, logos and trademarks mentioned in the following document are registered trademarks of Zortrax and are subject to legal protection.
  • Page 31 8. Fill the tank with resin. The resin level must fit the MIN and MAX marks. ©2019, Zortrax S.A. All rights reserved. All trade names, logos and trademarks mentioned in the following document are registered trademarks of Zortrax and are subject to legal protection.
  • Page 32 9. Install the UV cover on the printer. ©2019, Zortrax S.A. All rights reserved. All trade names, logos and trademarks mentioned in the following document are registered trademarks of Zortrax and are subject to legal protection.

  • Page 33: Platform Calibration

    2. Start the calibration with the options from the menu. Select Tools and then Calibration. At this point the printer will start to lift up the platform. ©2019, Zortrax S.A. All rights reserved. All trade names, logos and trademarks mentioned in the following document are registered trademarks of Zortrax and are subject to legal protection.
  • Page 34 4. Loosen the platform screw with an Allen key. Tap Next to continue. ©2019, Zortrax S.A. All rights reserved. All trade names, logos and trademarks mentioned in the following document are registered trademarks of Zortrax and are subject to legal protection.
  • Page 35 LCD screen during the printing process. ©2019, Zortrax S.A. All rights reserved. All trade names, logos and trademarks mentioned in the following document are registered trademarks of Zortrax and are subject to legal protection.

  • Page 36: Z-Suite Installation

    Remember to update Z-SUITE regularly. All updates are available at: https://support. zortrax.com/downloads/. ©2019, Zortrax S.A. All rights reserved. All trade names, logos and trademarks mentioned in the following document are registered trademarks of Zortrax and are subject to legal protection.

  • Page 37: Starting, Post-Processing And Removing A Print

    1. Remove the UV cover. If you haven’t calibrated the platform during the set-up of the printer, carry out this procedure now. ©2019, Zortrax S.A. All rights reserved. All trade names, logos and trademarks mentioned in the following document are registered trademarks of Zortrax and are subject to legal protection.
  • Page 38 3. Transfer the file from Z-SUITE to the printer (via Wi-Fi/Ethernet or using the USB drive) and start the printing process. ©2019, Zortrax S.A. All rights reserved. All trade names, logos and trademarks mentioned in the following document are registered trademarks of Zortrax and are subject to legal protection.
  • Page 39 (B). Be careful not to spill the liquid resin on the printer and its surroundings. Install the UV cover on the printer. ©2019, Zortrax S.A. All rights reserved. All trade names, logos and trademarks mentioned in the following document are registered trademarks of Zortrax and are subject to legal protection.
  • Page 40 7. Turn off the Ultrasonic Cleaner and remove the platform with the model. ©2019, Zortrax S.A. All rights reserved. All trade names, logos and trademarks mentioned in the following document are registered trademarks of Zortrax and are subject to legal protection.
  • Page 41 If you have problems with removing the print, use a cutting knife. 9. Remove the raft and support structures from the model. ©2019, Zortrax S.A. All rights reserved. All trade names, logos and trademarks mentioned in the following document are registered trademarks of Zortrax and are subject to legal protection.
  • Page 42 11. Unscrew the two screws that secure the resin tank and remove them (A). Next, remove the resin tank (B). Be careful not to spill the resin. ©2019, Zortrax S.A. All rights reserved. All trade names, logos and trademarks mentioned in the following document are registered trademarks of Zortrax and are subject to legal protection.
  • Page 43 13. Clean the resin tank with a paper towel. You can also use 99% isopropyl alcohol for that purpose. ©2019, Zortrax S.A. All rights reserved. All trade names, logos and trademarks mentioned in the following document are registered trademarks of Zortrax and are subject to legal protection.
  • Page 44 Ultrasonic Cleaner and turn on the device for about 30-60 seconds. ©2019, Zortrax S.A. All rights reserved. All trade names, logos and trademarks mentioned in the following document are registered trademarks of Zortrax and are subject to legal protection.

  • Page 45: Available Materials

    When 3D printing with the Zortrax Inkspire, the Manufacturer recommends using Zortrax certified materials to acquire the best possible quality of prints. ©2019, Zortrax S.A. All rights reserved. All trade names, logos and trademarks mentioned in the following document are registered trademarks of Zortrax and are subject to legal protection.

  • Page 46: Basic Maintenance And Service Work

    Zortrax Inkspire, together with specific check points, necessary activities and their frequency. ©2019, Zortrax S.A. All rights reserved. All trade names, logos and trademarks mentioned in the following document are registered trademarks of Zortrax and are subject to legal protection.
  • Page 47 NOTE! Do not use IPA or chemi- cal detergents for that purpose. ©2019, Zortrax S.A. All rights reserved. All trade names, logos and trademarks mentioned in the following document are registered trademarks of Zortrax and are subject to legal protection.
  • Page 48 -paper towels, bent, de- -IPA, formed, or -safety gloves perforated ©2019, Zortrax S.A. All rights reserved. All trade names, logos and trademarks mentioned in the following document are registered trademarks of Zortrax and are subject to legal protection.
  • Page 49 LCD screen. Follow completed the instructions in the manual: printing https://support.zortrax.com/ processes platform-calibration-inkspire/ ©2019, Zortrax S.A. All rights reserved. All trade names, logos and trademarks mentioned in the following document are registered trademarks of Zortrax and are subject to legal protection.

  • Page 50: Support And Troubleshooting

    In order to ensure safety of every 3D printer’s user, the Manufacturer provides various support while identifying and solving technical problems independently. In case of difficulties with operating a Zortrax 3D printer, at first you should seek guidance in this User Guide, check the manuals available at: http://support.zortrax.com/, or consult our technical specialists through the Support Form available at: http://support.zortrax.

  • Page 51: Error Messages

    (HDMI signal) contact Zortrax Support Center through the support form: https://support.zor- trax.com/support-form/. ©2019, Zortrax S.A. All rights reserved. All trade names, logos and trademarks mentioned in the following document are registered trademarks of Zortrax and are subject to legal protection.
  • Page 52 Contact Zortrax Support Center through the firmware updating the firmware. the support form: https://support.zor- trax.com/support-form/. ©2019, Zortrax S.A. All rights reserved. All trade names, logos and trademarks mentioned in the following document are registered trademarks of Zortrax and are subject to legal protection.
  • Page 53 More manuals and tips & tricks articles are available at our Support Center. www.zortrax.com ©2019, Zortrax S.A. All rights reserved. All trade names, logos and trademarks mentioned in the following document are registered trademarks of Zortrax and are subject to legal protection.

  • Page 54: Specification

    UV integrated light (wavelength 405 nm) Connectivity Wi-Fi, Ethernet, USB Operating system Android Processor Quad Core ©2019, Zortrax S.A. All rights reserved. All trade names, logos and trademarks mentioned in the following document are registered trademarks of Zortrax and are subject to legal protection.
  • Page 55 All information contained in this User Guide and specication is subject to change without notice. ©2019, Zortrax S.A. All rights reserved. All trade names, logos and trademarks mentioned in the following document are registered trademarks of Zortrax and are subject to legal protection.

  • Page 56: Recycling

    In case of questions and problems contact the Manufacturer through the support form: http://support.zortrax.com/support-form/. ©2019, Zortrax S.A. All rights reserved. All trade names, logos and trademarks mentioned in the following document are registered trademarks of Zortrax and are subject to legal protection.
