Summary of Contents for zortrax M200

  • Page 1 Unpacking & First Use SOURCE: http://working.support.zortrax.com/m200-unpacking-first-use/...

  • Page 2: Table Of Contents

    Table Of Content In the Box Preparing the Printer for Work Firmware Installation Z-SUITE Software Installation Loading the Material First Print...

  • Page 3: In The Box

    In the Box The graphic shows the whole box content.

  • Page 4: Preparing The Printer For Work

    Preparing the Printer for Work Open the box and remove the upper cushioning. Take the 3D printer out of the box. When lifting or moving the printer, do not grab:...
  • Page 5 belts shipping clips extruder Remove the foil.
  • Page 6 Remove the fillers. Remove the shipping clips. Remove the foam with accessories and the Starter Kit box.
  • Page 7 Lower the heatbed mount by pressing the places marked in the picture. Install the build platform onto the bolts marked in the picture. If you have any doubts during installation, take a look at the manual Platform Installation.
  • Page 8 Remember that the platform should be installed in your device with the perforated plate and its five silver calibration squares directed up. Plug the platform cable in. Both big and small connectors need to be plugged in.
  • Page 9 Stick the extruder cable clamps on the back of the printer. The upper clamp should be attached at 80 mm from the top of the printer and the bottom clamp at 90 mm from the bottom of the printer. Place the extruder cable in the clamps. Plug the extruder cable in.
  • Page 10 Plug the power cable in. Attach the material guide. Attach the spool holder.
  • Page 11 Place the material spool onto the spool holder. The spool should rotate anticlockwise. Feed the material into the extruder through the material guide. To calibrate the platform, select “Maintenance” and then “Autocalibration” from the menu.
  • Page 12 Follow the instructions displayed on the screen. For more details on calibration, see this video manual.

  • Page 13: Firmware Installation

    Firmware Installation Download the latest update of firmware at Zortrax Support in the Downloads section. To install the firmware, copy the Update.bin file to an SD card, insert the card into the printer and turn on the machine. The firmware updates automatically.

  • Page 14: Z-Suite Software Installation

    Z-SUITE Software Installation The latest Z-SUITE version can be found at Zortrax Support in the Downloads section. To install the Z-SUITE, you need the serial number of your printer. To find this number, go to “Information” option in the menu and choose “Serial Number.”...

  • Page 15: Loading The Material

    When the display shows the message “Insert new material,” insert the end of the material into the extruder and push the knob. Once the M200 finishes loading the material, it is ready to print. Remove the material remains using tweezers.

  • Page 16: First Print

    The printing procedure will begin automatically. The display will show information about the extruder heating level. Once the heating has been completed, the M200 will start printing. The bar on the display shows the progress of the print. Do not leave the printer unattended during the pre-print calibration.
