- Page 1 Platform Cable Replacement SOURCE: https://support.zortrax.com/inventure-platform-cable-replacement/...
-
Page 2: Table Of Contents
Table Of Content Opening the Front Door Moving up the Platform Unplugging the Power Cable Unplugging the Platform Cable, part 1 Unplugging the Platform Cable, part 2 Plugging in the Platform Cable, part 1 Plugging in the Platform Cable, part 2 Plugging in the Power Cable... -
Page 3: Opening The Front Door
Opening the Front Door Open the front door. -
Page 4: Moving Up The Platform
Moving up the Platform From the menu choose Maintenance and then Move the platform. Move up the platform using the upper button. DO NOT MOVE THE PLATFORM TOO HIGH. THE NOZZLES CANNOT HIT THE BUILD TRAY. -
Page 5: Unplugging The Power Cable
Unplugging the Power Cable Turn off the printer and unplug the power cable. -
Page 6: Unplugging The Platform Cable, Part 1
Unplugging the Platform Cable, part 1 Unplug the platform cable from the platform. - Page 7 Unplugging the Platform Cable, part 2 Unplug the platform cable from the bottom plate and remove the cable from the printer.
-
Page 8: Plugging In The Platform Cable, Part 1
Plugging in the Platform Cable, part 1 Prepare a new platform cable and plug it into the platform. - Page 9 Plugging in the Platform Cable, part 2 Plug in the other connector of the platform cable to the bottom plate.
-
Page 10: Plugging In The Power Cable
Plugging in the Power Cable Plug in the power cable and turn on the printer.
