:WGEN<w> Commands
:WGEN<w>:TRACk
Command Syntax
:WGEN<w>:TRACk <on_off>
<w> ::= 1 to (# WaveGen outputs) in NR1 format
<on_off> ::= {{1 | ON} | {0 | OFF}
The :WGEN<w>:TRACk ON command causes frequency, amplitude, offset, and
duty cycle adjustments to this waveform generator output signal to be tracked by
the other waveform generator output.
Not all waveform shapes can be frequency tracked. When :WGEN<w>:TRACk or
:WGEN<w>:TRACk:FREQuency is enabled, the other generator's waveform
selections (:WGEN<w>:FUNCtion) must be in the same group as this generator's
waveform:
Group 1
SINusoid
RAMP
SINC
CARDiac
GAUSsian
When tracking is enabled, adjustments for tracked settings in the other waveform
generator become unavailable.
Query Syntax
:WGEN<w>:TRACk?
The :WGEN<w>:TRACk? query returns whether tracking is on or off.
Return Format
<on_off><NL>
<on_off> ::= {1 | 0}
See Also •
•
•
•
•
1472
(see page 1610)
Group 2
SQUare
PULSe
":WGEN<w>:FUNCtion"
":WGEN<w>:TRACk:AMPLitude"
":WGEN<w>:TRACk:FREQuency"
":WGEN<w>:TRACk:PHASe"
":WGEN<w>:TRACk:CSIGnal"
Group 3
EXPRise
EXPFall
on page 1446
on page 1473
on page 1475
on page 1476
on page 1474
Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
Group 4
ARBitrary
