:DISPlay:ORDer

Query Syntax
:DISPlay:ORDer?
The :DISPlay:ORDer? query returns a list of digital channel numbers in screen
order, from top to bottom, separated by commas. Busing is displayed as digital
channels with no separator. For example, in the following list, the bus consists of
digital channels 4 and 5: DIG1, DIG4 DIG5, DIG7.
The :DISPlay:ORDer command is an obsolete command provided for compatibility to previous
N OTE
oscilloscopes. This command is only available on the MSO models.
Return Format
<order><NL>
<order> ::= Unquoted ASCII string
A return value is included for each digital channel. A return value of NONE indicates that a
N OTE
channel is turned off.
See Also •
Example Code
See complete example programs at:
starting on page 1619
Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
(see page 1610)
":DIGital<d>:POSition"
' DISP_ORDER - Set the order the channels are displayed on the
' analyzer. You can enter between 1 and 32 channels at one time.
' If you leave out channels, they will not be displayed.
' Display ONLY channel 0 and channel 10 in that order.
myScope.WriteString ":DISPLAY:ORDER 0,10"
Obsolete and Discontinued Commands
on page 397
Chapter 44, "Programming Examples,"
