Socket Bluetooth iPAQ User Manual page 20

7. In the next screen, uncheck Use default COM port. Click Next.
8. The software will report that the default setting is recommended. Click OK.
9. Select another COM port. If desired, check Auto Connect. Click Next.
WARNING! Do not select a COM port used by another device on your
system!
IMPORTANT! FOR SCENARIO 1 OR 2, REMEMBER WHICH COM NUMBER
YOU CHOSE! THIS IS THE LOCAL COM-CLIENT PORT NUMBER.
10. After COM port selection is complete,
(it is the Local COM-Client port
11. Edit the connection name and/or icon if desired. Click Next.
12. In the last screen, click Finish.
13. For Scenario 2 or 3, check the Local COM-Server port number.
Click Start | Control Panel | Bluetooth Local COM.
IMPORTANT!
• FOR SCENARIO 1, NOTE THE LOCAL COM-CLIENT NUMBER.
• FOR SCENARIO 2, NOTE BOTH COM PORT NUMBERS.
• FOR SCENARIO 3, NOTE THE LOCAL COM-SERVER NUMBER.
20
remember the COM port number
number). Click Next.
