A F
PPENDIX
C
HANGING THE
Check the table below to determine the default data mode of your Bluetooth CHS.
The part number is printed on a barcode inside the battery door. By default, the
latest versions of the Bluetooth CHS send data in packet mode in order to support
Error Proof Protocol.
Bluetooth CHS version
7E2 gray
7E2 yellow
7M
7M yellow
7P
7NRx
7M
7P
7X
7XRx
Note: In raw data format, the ACK/NAK handshaking is disabled for decode data.
There are three ways to configure the data mode of the Bluetooth CHS:
• Binary data: Compatible with all versions of the Bluetooth CHS. Programmers
can change the data mode of the Bluetooth CHS by sending the following
binary data to it:
Send Raw Decode Data:
0x07 0xC6 0x04 0x00 0xFF 0xEE 0x00 0xFD 0x42
Send Packeted Decode Data:
0x07 0xC6 0x04 0x00 0xFF 0xEE 0x01 0xFD 0x41
• Scan Params configuration utility: Compatible with all versions of the Bluetooth
CHS, available for Windows Mobile or Palm OS. Download the utility from:
http://www.socketmobile.com/support/support_bar.asp
APPENDIX F: CHANGING THE DATA MODE
D M
ATA ODE
Part Number
8550-00050
8550-00051
8550-00052
8550-00038
8550-00041
8550-00039
8550-00046
8550-00005
8550-00008
8550-00014
8550-00006
8550-00009
8550-00015
Default Data Mode
packet
packet
packet
packet
packet
packet
raw
raw
101
