4.5.5. NAND Flash Interface Design Guidelines

GUIDELINE: Ensure that the selected NAND flash device is an 8-bit ONFI 1.0
(or later) compliant device.
The NAND flash controller in the HPS requires:
• The external flash device to be 8-bit ONFI 1.0 compliant
• Single-level cell (SLC) or multi-level cell (MLC)
• Page size: 512 bytes, 2 KB, 4 KB or 8 KB
• Pages per block: 32, 64, 128, 256, 384 or 512
• Error correction code (ECC) sector size can be programmed to 512 bytes (for 4-,
8- or 16-bit correction) or 1024 bytes (24-bit correction)
You cannot export the NAND interface to FPGA.
Note: Refer to Supported Flash Devices for Cyclone V and Arria V SoC
NAND devices.

4.5.6. UART Interface Design Guidelines

GUIDELINE: Properly connect flow control signals when routing the UART
signals through the FPGA fabric.
When routing UART signals through the FPGA, the flow control signals are available. If
flow control is not being used, connect the FPGA signals as shown in the following
table.
Table 9. UART Connections to Disable Flow Control
Signal
CTS
DSR
DCD
RI
DTR
RTS
OUT1_N
OUT2_N
AN 796: Cyclone V and Arria V SoC Device Design Guidelines
46
4. Board Design Guidelines for SoC FPGAs
Direction
Input
Input
Input
Input
Output
Output
Output
Output
AN-796 | 2018.06.18
for a list of supported
Connection
Low
High
High
High
No-connect
No-connect
No-connect
No-connect
