3. Design Guidelines for HPS portion of SoC FPGAs
AN-796 | 2018.06.18
The only HPS I/O constraints you must manage are for HPS Dedicated Function Pins
and HPS Dedicated I/O. Constraints such as drive strength, I/O standards, and weak
pull-up enables are added to the Intel Quartus Prime project just like FPGA constraints
and are applied to the HPS at boot time when the second stage bootloader configures
the I/O. For FPGA I/O, the I/O constraints are applied to the FPGA configuration file.
Note: During power up, the HPS Dedicated I/O required for boot flash devices are configured
by the Boot ROM, depending on the BSEL values.

3.3. HPS Clocking and Reset Design Considerations

The main clock and resets for the HPS subsystem are
HPS_nPOR, HPS_nRST
generates the clocks for the MPU, L3/L4 sub-systems, debug sub-system and the
Flash controllers. It can also be programmed to drive the Peripheral and SDRAM PLLs.
HPS_CLK2
the SDRAM PLLs.
HPS_nPOR
reset resource. As for the
either a standard POR delay or a fast POR delay for the HPS block.
Note: Refer to the
and SX Device Family Pin Connection Guidelines
the HPS clock and reset pins.
and
HPS_PORSEL
meanwhile can be used as an alternative clock source to the Peripheral and
provides a cold reset input, and
HPS_PORSEL
Cyclone V Device Family Pin Connection Guidelines
HPS_CLK1, HPS_CLK2,
. sources the Main PLL that
HPS_CLK1
provides a bidirectional warm
HPS_nRST
, it is an input pin that can be used to select
for more information on connecting
AN 796: Cyclone V and Arria V SoC Device Design Guidelines
or Arria V GT, GX, ST,
19
