Noggin 6-SmartTow Configuration Assembly

6.2 Noggin 250

The fully-assembled Noggin 250 in the SmartTow configuration is shown in Figure 6-1. The
system is shown in field operation in Figure 6-2. Follow the directions below to assemble the
configuration.
Figure: 6-8 Noggin 250 SmartTow system
Figure: 6-9 Noggin 250 SmartTow in operation. Note the belt battery used to power the system.
