13-Survey & Map Mode
The choices available for Station Interval are:
1) Short
2) Normal
3) Long
4) X-Long
5) Normal x10
6) Normal x20
7) Normal x 40
8) Normal x 50
9) Normal x 100
Each choice listed will be followed by an actual value in meters or inches depending on which
units are selected and which Noggin system is being used. Here is a chart showing the station
interval for each system and setting. Note the calculations for Data per Screen assumes that the
Plot Interval is set to Normal for the particular Noggin system (Noggin 100/250 = 2 pixels per
trace and Noggin 500/1000 = 1 pixel per screen). If this assumption is not true, see the formula
after the charts for calculating this value.
Setting
Normal
X-Long
Norm x10
Norm x20
Norm x40
Norm x50
Norm x100
Setting
Normal
X-Long
Norm x10
Norm x20
Norm x40
Norm x50
Norm x100
N
OGGIN
Station Interval
Short 5.0 cm or 1.92 in
10.0 cm or 3.84 in
Long 20.0 cm or 7.68 in
50.0 cm or 19.20 in
100.0 cm or 38.4 in
200.0 cm or 76.8 in
400.0 cm or 153.6 in
500.0 cm or 192.0 in
1000.0 cm or 384.0 in
N
OGGIN
Station Interval
Short 2.5 cm or 0.96 in
5.0 cm or 1.92 in
Long 10.0 cm or 3.84 in
25.0 cm or 9.6 in
50.0 cm or 19.20 in
100.0 cm or 38.4 in
200.0 cm or 76.8 in
250.0 cm or 96.0 in
500.0 cm or 192.0 in
100 S
YSTEM
Data per Screen
16 m or 51.2 ft
32 m or 102.4 ft
64 m or 204.8 ft
160 m or 512 ft
320 m or 1024 ft
640 m or 2048 ft
1280 m or 4096 ft
1600 m or 5120 ft
3200 m or 10240 ft
250 S
YSTEM
Data per Screen
8 m or 25.6 ft
16 m or 51.2 ft
32 m or 102.4 ft
80 m or 256 ft
160 m or 512 ft
320 m or 1024 ft
640 m or 2048 ft
800 m or 2560 ft
1600 m or 5120 ft
