HP 3500 Series Advanced Traffic Management Manual page 269

HP Switch(config)# qos dscp-map 000010 priority 6 name 'Level 6'
HP Switch(config)# qos dscp-map 000101 priority 4 name 'Level 4'
HP Switch(config)# show qos dscp-map
DSCP -> 802.p priority mappings
DSCP CodePoint DSCP Value 802.1p tag
-------------- ---------- ----------- --------------------------------
000000
000001
000010
000011
000100
000101
.
Figure 5-19. Configuring DSCP Policies in the DSCP Table
HP Switch(config)# qos type-of-service diff-services 001100 dscp 000010
HP Switch(config)# qos type-of-service diff-services 001101 dscp 000101
HP Switch(config)# show qos type-of-service
Type of Service : Differentiated Services
Codepoint DSCP Policy | Priority
--------- ----------- + -----------
000000
000001
000010
000011
000100
000101
000110
000111
001000
001001
001010
001011
001100 000010
001101 000101
001110
. .
Figure 5-20. Assigning DSCP Policies to Outbound Packets Based on the DSCP Codepoint from Upstream
Devices
0 No-override
1 No-override
2 6
3 No-override
4 No-override
5 4
. .
3. Assign the new policies to mark matching packets with the specified
codepoints.
| No-override
| No-override
| 6
| No-override
| No-override
| 4
| No-override
| No-override
| No-override
| No-override
| No-override
| No-override
| 6
| 4
| No-override
.
Quality of Service: Managing Bandwidth More Effectively
DSCP Policy name
Level 6
Level 4
The specified DSCP policies
overwrite the original DSCPs in
matching packets, and use the
802.1p priorities configured in
the DSCP policies in step 2.
Globally-Configured QoS
5-51
