HP 3500 Series Advanced Traffic Management Manual page 257

HP Switch(config)# qos device-priority 10.28.31.1 dscp 000111
HP Switch(config)# qos device-priority 10.28.31.130 dscp 000101
HP Switch(config)# qos device-priority ipv4 10.28.32.100/24 dscp 000010
HP Switch(config)# qos device-priority 2001:db8:2:1:212:79ff:fe88:a100 dscp 000
HP Switch(config)# qos device-priority ipv6 2001:db8:3:3/64 dscp 000010
HP Switch(config)# show qos device-priority
Device priorities
Device Address
--------------------------------------------
10.28.31.1
10.28.31.130
10.28.32.100/24
2001:db8:2:1:212:79ff:fe88:a100
2001:db8:3:3/64
Figure 5-12. The Completed Device-Priority/Codepoint Configuration
3. Assign the DSCP policies to the specified IP-device addresses and display
the result.
The switch applies the DSCP policies in Figure 5-11 to IP packets with the
specified IP addresses and subnet masks (source or destination) received in
the switch. The switch manages the packets as follows:
■ Overwrites the original DSCPs in the selected packets with the new
DSCPs specified in the above policies.
Assigns the 802.1p priorities in the above policies to the appropriate
■
packets.
Quality of Service: Managing Bandwidth More Effectively
Apply rule | DSCP
---------- + ------ -----------
Priority
Priority
Priority
Priority
Priority
Globally-Configured QoS
Priority
| 000111 7
| 000101 5
| 000010 1
| 000101 3
| 000010 1
5-39
