Sliding Bolt (Sbg) - Mul-t-lock Padlock E Series Service Manual

38
Sliding Bolt (SBG)
11
10
No. Part
1 Key
2 Cylinder
3 Cam limiter
4 Activator cam
9
8
7
6
5 4 3
No. Part
Ball bearing
5
8 mm
6 Locking bolt pin
7 Sliding bolt
Bolt retaining pin
8
Spring
2
No. Part
9 Bolt retaining pin
10 Socket screw M5
11 Lock body
Sliding Bolt (SBG)
1
