Pop-Open Shackle No. 8 - Mul-t-lock Padlock E Series Service Manual

Hide thumbs
Table of Contents

Advertisement

20
Pop-Open
Shackle No. 8
6
7
8
9
10
11
12
13
14
No.
Part
1
Key
2
Shell
3
Shackle Spring
4
Shackle
5
Long latch
5
No.
Part
6
Thrust Plate
7
Short latch
8
Latch Springs
9
Core
Threaded pin
10
10/32" UNF
Pop-Open Shackle No. 8
4
3
2
1
No.
Part
11
Plug
12
C8 Hive
13
Shutter
14
Shutter Spring
