Mul-t-lock Padlock E Series Service Manual page 20

18
3
• Turn the core upside down and pull
out the cylinder so that the plastic
catch can be mounted.
• NOTE: Do not pull the cylinder out
of the core more than two-thirds of
the way!
• Mount the plastic catch and remove
the cylinder.
A
4
• Insert the key into the
cylinder and turn it until the
pins can be removed from
the plug.
Pop-Open Shackle / Disassembly Instructions
B C
3
4
