Mul-t-lock Padlock E Series Service Manual page 29

Disassembly Instructions
1
• Unlock the padlock
with the operating key.
• Mount the
disassembling ring
onto the bolt as
illustrated (1A).
• Remove the bolt (8) by
pulling it out.
2
• Remove pin (6) and
spring (7).
• Push grooved pin (17)
up while sliding core out.
SBC-13 Sliding Bolt / Disassembly
Instructions
1A
17
8
1
6
7
2
