Mul-t-lock Padlock E Series Service Manual page 31

5
• Turn the core upside down and pull
out the cylinder so that the plastic
catch can be mounted.
• NOTE: Do not pull the cylinder out of
the core more than two-thirds of the
way!
• Mount the plastic catch and remove
the cylinder.
A
6
• Insert the key into the cylinder and
turn it until the pins can be removed
from the plug.
• Assembly tip
Latch (20) goes inside before
adaptor (14).
SBC-13 Sliding Bolt / Disassembly
Instructions
20
B
14
C
5
6
