4 - Language Dictionary
[SOURce:]LIST:TRANsient:TWIDth
[SOURce:]LIST:TRANsient:TWIDth:POINts?
Channel Specific
This command sets the transient pulse width for each step when the generator is in PULSe mode.
LIST:TRANsient:TWIDth:POINts? returns the number of points programmed.
Command Syntax
Parameters
*RST Value
Examples
Query Syntax
Returned Parameters
Related Commands
[SOURce:]LIST:VOLTage
[SOURce:]LIST:VOLTage:POINts?
Channel Specific
This command specifies the voltage setting for each list step. Refer to Table 4-1 for model-specific
programming ranges. LIST:VOLTage:POINts? returns the number of points programmed.
Command Syntax
Parameters
Examples
Query Syntax
Returned Parameters
Related Commands
[SOURce:]LIST:VOLTage:RANGe
[SOURce:]LIST:VOLTage:RANGe:POINTs?
Channel Specific
This command sets the voltage range for each list step. There are two voltage ranges.
High Range: model dependent, see Table 4-1
Low Range: model dependent, see Table 4-1
When you program a range value, the load automatically selects the range that corresponds to the value
that you program. If the value falls in a region where ranges overlap, the load selects the range with the
highest resolution. LIST:VOLTage:RANGe:POINts? returns the number of points programmed.
If the existing IMMediate, TRANsient, and TRIGgered voltage list settings are outside the
NOTE:
new range, a list error is generated when the list is initiated and the list does not execute.
86
[SOURce:] LIST:TRANsient:TWIDth <NRf+> {,<NRf+>}
0.00005s - 4s | MAXimum | MINimum
Unit seconds
0.0005s
LIST:TRAN:TWID .005
[SOURce:]LIST:TRANsient:TWIDth?
[SOURce:]LIST:TRANsient:TWIDth:POINts?
<NR3> {,<NR3>}
TRAN:TWID
[SOURce:]LIST:VOLTage[:LEVel] <NRf+> {,<NRf+>}
0 through MAX | MINimum | MAXimum
V (volts)
Unit
LIST:VOLT 2.5,3.0,3.5
LIST:VOLT MAX,3.5,2.5,MIN
[SOURce:]LIST:VOLTage[:LEVel]?
[SOURce:]LIST:VOLTage:POINts?
<NR3> {,<NR3>}
VOLT
LIST:TRAN:TWID 5E-4
