[Source:]List:current:range [Source:]List:current:range:points; [Source:]List:current:slew [Source:]List:current:slew:points - Keysight Technologies N3301A Programming Manual

[SOURce:]LIST:CURRent:RANGe
[SOURce:]LIST:CURRent:RANGe:POINts?
Channel Specific
This command sets the current range for each list step. There are two current ranges.
High Range: model dependent, see Table 4-1
Low Range: model dependent, see Table 4-1
When you program a range value, the load automatically selects the range that corresponds to the value
that you program. If the value falls in a region where ranges overlap, the load selects the range with the
highest resolution. LIST:CURRent:RANGe:POINts? returns the number of points programmed.
If the existing IMMediate, TRANsient, and TRIGgered current list settings are outside the
NOTE:
new range, a list error is generated when the list is initiated and the list does not execute.
Command Syntax
Parameters
*RST Value
Examples
Query Syntax
Returned Parameters
Related Commands
[SOURce:]LIST:CURRent:SLEW
[SOURce:]LIST:CURRent:SLEW:POINts?
Channel Specific
This command sets the current slew rate for each step. This command programs both positive and
negative going slew rates. MAXimum sets the slew to its fastest possible rate. MINimum sets the slew to
its slowest rate. LIST:CURRent:SLEW:POINts? returns the number of points programmed.
Command Syntax
Parameters
*RST Value
Examples
Query Syntax
Returned Parameters
Related Commands
[SOURce:]LIST:CURRent:RANGe <NRf+> {,<NRf+>}
0 through MAX | MINimum | MAXimum
A (amperes)
Unit
MAXimum (high range)
LIST:CURR:RANGE MIN
[SOURce:]LIST:CURRent:RANGe?
[SOURce:]LIST:CURRent:RANGe:POINts?
<NR3> {,<NR3>}
CURR:RANG
[SOURce:]LIST:CURRent:SLEW[:BOTH] <NRf+> {,<NRf+>}
0 to 9.9E37 | MAXimum | MINimum
A (amperes per second)
Unit
MAXimum
LIST:CURR:SLEW 50
[SOURce:]LIST:CURRent:SLEW[:BOTH]?
[SOURce:]LIST:CURRent:SLEW:POINts?
<NR3> {,<NR3>}
CURR:SLEW
Language Dictionary - 4
LIST:CURR:SLEW MAX
79
