Port Commands

These commands control the general purpose digital port on the electronic load modules.

PORT0

Channel Specific
This command sets the state of the general purpose digital port on the specified electronic load module.
A value of 1 sets the state high, a 0 sets the state low.
Command Syntax
Parameters
*RST Value
Examples
Query Syntax
Returned Parameters
Related Commands

PORT1

This command sets the state of the two general purpose digital ports on the mainframe. The value that
you send is the equivalent of a 2-bit binary word. Use the following values to set the individual bits. Note
that the digital port on the mainframe can also be programmed using lists.
value
Dig 2
0
1
2
3
Command Syntax
Parameters
*RST Value
Examples
Query Syntax
Returned Parameters
Related Commands
PORT0[:STATe] <bool>
0 | 1 | OFF | ON
OFF
PORT0 1
PORT0[:STATe]?
0 | 1
PORT1
Dig 1
Lo
Lo
Lo
Hi
Hi
Lo
Hi
Hi
PORT1[:LEVel] <NR1>
0 | 1 | 2 | 3
0
PORT1 1
PORT1?
<NR3>
PORT0
PORT0 0N
PORT1 3
Language Dictionary - 4
77
