A - SCPI Command Tree
SENSe
:CURRent
:RANGe <n>
:SWEep
:OFFSet
:POINts <n>
:TINTerval <n>
:WINDow [:TYPE] <type>
:VOLTage
:RANGe <n>
[SOURce:]
CURRent
[:LEVel]
[:IMMediate][:AMPLitude] <n>
:TRIGgered [:AMPLitude] <n>
:MODE <mode>
:PROTection
[:LEVel] <n>
:DELay <n>
:STATe <bool>
:RANGe <n>
:SLEW
[:BOTH] <n>
:NEGative <n>
:POSitive <n>
:TLEVel <n>
FUNCtion | MODE <mode>
:MODE <mode>
LIST
:COUNt <n>
:CURRent
[:LEVel] <n> {,<n>}
:POINts?
:RANGe <n> {,<n>}
:POINts?
:SLEW
[:BOTH] <n> {,<n>}
:POINts?
:NEGative <n> {,<n>}
:POSitive <n> {,<n>}
:TLEVel <n> {,<n>}
:POINts?
:DWELl <n> {,<n>}
:POINts?
:FUNCtion | MODE <mode> {,<mode>}
:POINts?
:RESistance
[:LEVel] <n> {,<n>}
:POINts?
:RANGe <n> {,<n>}
:POINts?
106
Selects the current measurement range
Defines the data offset in the measurement
Define the number of data points in the measurement
Sets the digitizer sample spacing
Sets the measurement window function (HANN | RECT)
Selects the voltage measurement range
Sets the input current
Sets the triggered input current
Sets the current mode (FIX |LIST)
Sets the current protection level
Sets the delay before the current protection is activated
Enables/disables current limit protection
Sets the input current range
Sets the current slew rate
Sets the current slew rate for negative transitions
Sets the current slew rate for positive transitions
Sets the transient input current
Sets the regulation mode (CURR | RES | VOLT)
Selects what controls the regulation mode (FIX | LIST)
Specifies the number of times the list is cycled
Specifies the current setting for each step
Returns the number of current list points
Specifies the current range for each step
Returns the number of current range list points
Sets the current slew rate for each step
Returns the number of current slew list points
Sets the negative current slew rate for each step
Sets the positive current slew rate for each step
Sets the transient input current for each step
Returns the number of current transient list points
Specifies the time period of each step
Returns the number of dwell list points
Sets the list regulation mode (CURR | RES | VOLT)
Returns the number of function list points
Specifies the resistance setting for each step
Returns the number of resistance list points
Specifies the resistance range for each step
Returns the number of resistance range list points
