The MCB (Molded Case Circuit Breaker) could trip when powering on the FujiFilm FVR-Micro due to:

1. Overcurrent at power-on caused by inrush current or wiring issues.
2. Use of an MCCB with a capacity exceeding the recommended rating.
3. Faults in the inverter such as short circuits or internal component failures.
4. Improper grounding or wiring errors.
5. Power supply issues like incorrect voltage or frequency.

These factors can trigger the protective device to disconnect power to prevent damage.

This answer is automatically generated

Summary of Contents for FujiFilm FVR-Micro

Page 1: Instruction Manual
Instruction Manual Advanced simple Inverter FVR-Micro Thank you for purchasing our FVR-Micro of inverters. • This product is designed to drive a three-phase induction motor. Read through this instruction manual and be familiar with the handling procedure for correct use.
Page 2 Copyright © 2017 Fuji Electric Co., Ltd. All rights reserved. No part of this publication may be reproduced or copied without prior written permission from Fuji Electric Co., Ltd. All products and company names mentioned in this manual are trademarks or registered trademarks of their respective holders.
Page 3: Table Of Contents
Table of Contents Preface ..............2 Chapter 5 FUNCTION CODES ......5-1 5.1 Function Code Tables ........5-1 Safety precautions............. 3 5.2 Details of Function Codes ......5-18 Chapter 1 BEFORE USING THE INVERTER..1-1 1.1 Acceptance Inspection ........ 1-1 Chapter 6 TROUBLESHOOTING ......6-1 1.2 External Views..........
Page 4 Preface Thank you for purchasing our FVR-Micro of inverters. This product is designed to drive a three-phase induction motor. Read through this instruction manual and be familiar with proper handling and operation of this product. Improper handling might result in incorrect operation, a short life, or even a failure of this product as well as the motor.
Page 5: Safety Precautions
These safety precautions are of utmost importance and must be observed at all times. Application • FVR-Micro is designed to drive a three-phase induction motor. Do not use it for single-phase motors or for other purposes. Fire or an accident could occur.
Page 6 • Do not support the inverter by its terminal block cover during transportation. Doing so could cause a drop of the inverter and injuries. • Prevent lint, paper fibers, sawdust, dust, metallic chips, or other foreign materials from getting into the inverter or from accumulating on the heat sink. Otherwise, a fire or an accident might result.
Page 7 • Generally, control signal wires are not reinforced insulation. If they accidentally touch any of live parts in the main circuit, their insulation coat may break for any reasons. In such a case, an extremely high voltage may be applied to the signal lines. Make a complete remedy to protect the signal line from contacting any hot high voltage lines.
Page 8 • If you enable the "restart mode after momentary power failure" (Function code F14 = 4 or 5), then the inverter automatically restarts running the motor when the power is recovered. (Design the machinery or equipment so that human safety is ensured after restarting.) •...
Page 9: General Precautions
Disposal • Handle the inverter as an industrial waste when disposing of it. Otherwise injuries could occur. Others • Never attempt to modify the inverter. Doing so could cause electric shock or injuries. GENERAL PRECAUTIONS Drawings in this manual may be illustrated without covers or safety shields for explanation of detail parts.
Page 10: Chapter 1 Before Using The Inverter
Chapter 1 BEFORE USING THE INVERTER 1.1 Acceptance Inspection Unpack the package and check that: (1) An inverter and instruction manual (brief manual) are contained in the package. (2) The inverter has not been damaged during transportation—there should be no dents or parts missing.
Page 11: External Views
1.2 External Views External views Control circuit keypad Main nameplate terminal Block cover Main circuit terminal block cover [ FVR0.4AS1S-7] Control circuit terminal Block keypad Cooling fan cover Main circuit terminal block cover [ FVR3.7AS1S-4]...
Page 12 Wiring section Barrier for the RS-485 communication port Control signal wire port Main circuit wire port Grounding wire port [Frame1] [Frame2] Barrier for the RS-485 communication port Main circuit wire port Grounding wire port [Frame3]...
Page 13: Chapter 2 Mounting And Wiring Of The Inverter
The temperature of the heat sink may rise up to approx. 90°C during operation of the inverter, so the inverter should be mounted on a base made of material that can withstand temperatures of this level. FVR-Micro Left Right 10mm 10mm Install the inverter on a base made of metal or other non-flammable material.
Page 14: Wiring
(3) Mounting direction Secure the inverter to the mounting base with four screws or bolts (M4) so that the FVR-Micro logo faces outwards. (FVR0.4AS1S-7 and FVR0.75AS1S-7 use two screws or bolts.) Tighten those screws or bolts perpendicular to the mounting base.
Page 15: Terminal Arrangement And Screw Specifications
2.3.2 Terminal arrangement and screw specifications The figures below show the arrangement of the main and control circuit terminals which differ according to inverter type. The two terminals prepared for grounding, which are indicated by the symbol G in Figures A to C, make no distinction between the power supply side (primary circuit) and the motor side (secondary circuit).
Page 16 (2) Arrangement of the control circuit terminals (common to all FVR-Micro models) 1 : 5V 2 : Ground 3 : NC 4 : DX- 5 : DX+ 6 : NC 7 : Ground 8 : 5V 8 7 6 5 4 3 2 1 FWD REV Screw size : M2.5 Tightening torque : 0.4Nm...
Page 17: Recommended Wire Sizes
2.3.3 Recommended wire sizes Table 2.6 lists the recommended wire sizes. The recommended wire sizes for the main circuit terminals for an ambient temperature of 50°C are indicated for two types of wire: HIV single wire (for the maximum allowable temperature 75°C) . Table 2.6 Recommended Wire Sizes Recommended wire size (mm Main circuit...
Page 18: Wiring Precautions
2.3.4 Wiring precautions Follow the rules below when performing wiring for the inverter. (1) Make sure that the source voltage is within the rated voltage range specified on the nameplate. (2) Be sure to connect the power wires to the main circuit power input terminals L1/R, L2/S and L3/T (for three-phase voltage input) or L1/L and L2/N (for single-phase voltage input) of the inverter.
Page 19: Wiring For Main Circuit Terminals And Grounding Terminals
2.3.5 Wiring for main circuit terminals and grounding terminals Follow the procedure below. Figure 2.3 illustrates the wiring procedure with peripheral equipment. Wiring procedure ① Grounding terminal ② Inverter output terminals (U, V, and W) and grounding terminal ③ Braking resistor connection terminals (P and DB)* ④...
Page 20 The wiring procedure for the FVR0.75AS1S-4 is given below as an example. For other inverter types, perform wiring in accordance with their individual terminal arrangement. ① Grounding terminal ( G) Be sure to ground either of the two grounding terminals for safety and noise reduction. It is stipulated by the Electric Facility Technical Standard that all metal frames of electrical equipment must be grounded to avoid electric shock, fire and other disasters.
Page 21 Driving 400 V series motor • If a thermal relay is installed in the path between the inverter and the motor to protect the motor from overheating, the thermal relay may malfunction even with a wiring length shorter than 50 m. In this situation, add an output circuit filter (option) or lower the carrier frequency (Function code F26: Motor sound (Carrier frequency)).
Page 22: Wiring For Control Circuit Terminals
2.3.6 Wiring for control circuit terminals In general, sheaths and covers of the control signal cables and wires are not specifically de- signed to withstand a high electric field (i.e., reinforced insulation is not applied). Therefore, if a control signal cable or wire comes into direct contact with a live conductor of the main circuit, the insulation of the sheath or the cover might break down, which would expose the signal wire to a high voltage of the main circuit.
Page 23 Table 2.7 Symbols, Names and Functions of the Control Circuit Terminals Symbol Name Functions [13] Power Power supply (+10 VDC) for an external frequency command potentiometer supply (Potentiometer: 1 to 5 kΩ) A potentiometer of 1/2 W rating or more should be connected potenti- Allowable maximum output current: 10mA.
Page 24 Table 2.7 Symbols, Names and Functions of the Control Circuit Terminals (Continued) Symbol Name Functions - These low level analog signals are especially susceptible to the external noise effects. Route the wiring as short as possible (within 20 m) and use shielded wires. In principle, ground the shielded sheath of wires;...
Page 25 Table 2.7 Symbols, Names and Functions of the Control Circuit Terminals (Continued) Symbol Name Functions [X1] Digital (1) The various signals such as "Coast to a stop," "Enable external alarm input 1 trip," and "Select multistep frequency" can be assigned to terminals [X1] to [X3], [FWD] and [REV] by setting function codes E01 to E03, E98, and E99.
Page 26 Table 2.7 Symbols, Names and Functions of the Control Circuit Terminals (Continued) Symbol Name Functions Using a relay contact to turn [X1], [X2], [X3], [FWD] or [REV] ON or OFF Figure 2.7 shows two examples of a circuit that uses a relay contact to turn control signal input [X1], [X2], [X3], [FWD] or [REV] ON or OFF.
Page 27 Table 2.7 Symbols, Names and Functions of the Control Circuit Terminals (Continued) Symbol Name Functions The monitor signal for analog DC voltage (0 to +10 VDC) is output. The [FMA] Analog signal functions can be selected from the following with function code F31. monitor - Output frequency (before slip compensation) - Output frequency (after slip compensation)
Page 28 Table 2.7 Symbols, Names and Functions of the Control Circuit Terminals (Continued) Symbol Name Functions Connecting programmable controller (PLC) to terminal [Y1] Figure 2.9 shows two examples of circuit connection between the transistor output of the inverter’s control circuit and a PLC. In example (a), the input circuit of the PLC serves as a sink for the control circuit, whereas in example (b), it serves as a source for the control circuit.
Page 29: Setting Up The Jumper Switches
- Route the wiring of the control terminals as far from the wiring of the main circuit as possible. Otherwise electric noise may cause malfunctions. - Fix the control circuit wires inside the inverter to keep them away from the live parts of the main circuit (such as the terminal block of the main circuit).
Page 30 Figure 2.11 shows the locations of jumper switches and the RJ-45 connector. ① ② ③ Figure 2.11 Locations of Jumper Switches and RJ-45 Connector 2-18...
Page 31: Chapter 3 Operation Using The Keypad
In Programming mode: Pressing this key displays the function codes and sets their data entered with the keys or the POT. In Alarm mode: Pressing this key displays detailed alarm information. * FVR-Micro features three operation modes: Running, Programming, and Alarm. Refer to Section 3.2 "Overview of Operation Modes."...
Page 32: Overview Of Operation Modes
Simultaneous keying Simultaneous keying means pressing two keys at the same time (expressed by "+"). FVR-Micro supports simultaneous keying as listed below. (For example, the expression " keys" stands for pressing the key while holding down the key.) Table 3.2 Simultaneous Keying...
Page 33: Chapter 4 Running The Motor
Chapter 4 RUNNING THE MOTOR 4.1 Test Run 4.1.1 Checking prior to powering on Check the following prior to powering on the inverter. (1) Check the wiring to the power input terminals (L1/R, L2/S and L3/T or L1/L and L2/N) and inverter output terminals (U, V and W).
Page 34: Preparation Before A Test Run Configuring Function Code Data
4.1.3 Preparation before a test run--Configuring function code data Before running the motor, configure function code data specified in Table 4.1 in accordance with the motor ratings and your system design values. The motor ratings are printed on the nameplate of the motor.
Page 35: Test Run
4.1.4 Test run If the user configures the function codes wrongly without completely understanding this Instruction Manual, the motor may rotate with a torque or at a speed not permitted for the machine. Accident or injury may result. Follow the descriptions given in Section 4.1.1 "Checking prior to powering on" to Section 4.1.3 "Preparation before a test,"...
Page 36: Chapter 5 Function Codes
FUNCTION CODES 5.1 Function Code Tables Function codes enable the FVR-Micro of inverters to be set up to match your system requirements. Each function code consists of a 3-letter alphanumeric string. The first letter is an alphabet that identifies its group and the following two letters are numerals that identify each individual code in the group.
Page 37 4th digit of the set data will not be displayed; however they will be processed correctly. The following tables list the function codes available for the FVR-Micro of inverters. F codes: Fundamental Functions...
Page 38 Change Incre- Data Default Code Name Data setting range Unit when ment copying running setting Operation Method – – 0: RUN/STOP keys on keypad (Motor rotational direction specified by terminal command FWD/REV) 1: Terminal command FWD or REV 2: RUN/STOP keys on keypad (forward) 3: RUN/STOP keys on keypad (reverse) Maximum Frequency 1 25.0 to 400.0...
Page 39 (F codes continued) Change Incre- Data Default Code Name Data setting range Unit when ment copying setting running Bias -100.0 to 100.0 *1 0.01 0.00 (Frequency command 1) DC Braking 1 0.0 to 60.0 (Braking starting frequency) (Braking level) 0 to 100 *2 (Braking time) 0.00 (Disable), 0.01 to 30.00 0.01...
Page 40 (F codes continued) Change Incre- Data Default Code Name Data setting range Unit when ment copying setting running Current Limiter Disable (No current limiter works.) – – (Mode selection) Enable at constant speed (Disable during ACC/DEC) Enable during ACC/constant speed operation (Level) 20 to 180 : 3.7 kW(5HP)
Page 41 E codes: Extension Terminal Functions Change Incre- Data Default Code Name Data setting range Unit when ment copying setting running Terminal [X1] Function Selecting function code data assigns the – – corresponding function to terminals [X1] to [X3] as listed below. Terminal [X2] Function 0 (1000): Select multistep frequency (SS1) –...
Page 42 (E codes continued) Change Incre- Data Default Code Name Data setting range Unit when ment copying setting running Terminal [Y1] Function – – Selecting function code data assigns the corresponding function to terminals [Y1] and Terminal [30A/B/C] – – [30A/B/C] as listed below. Function 0 (1000): Inverter running (RUN)
Page 43 (E codes continued) Change Incre- Data Default Code Name Data setting range Unit when ment copying setting running Current Detection 2 0.00 (Disable), 0.01 to 100.0 0.01 Table (Level) Current value of 1 to 200% of the inverter rated current (Timer) 0.01 to 600.00 *1 0.01...
Page 44 (E codes continued) Change Incre- Data Default Code Name Data setting range Unit when ment copying setting running 0: None Built-in – 1: Auxiliary frequency command 1 Potentiometer 2: Auxiliary frequency command 2 (Function 3: PID process command 1 selection) Selecting function code data assigns the Terminal [12] –...
Page 45 C codes: Control Functions Change Incre- Data Default Code Name Data setting range Unit when ment copying setting running Jump Frequency 1 0.0 to 400.0 (Hysteresis width) 0.0 to 30.0 Multistep Frequency 1 0.00 to 400.0 *1 0.01 0.00 0.00 0.00 0.00 0.00...
Page 46 (C codes continued) Change Incre- Data Default Code Name Data setting range Unit when ment copying setting running 0.00 to 400.00 0.01 – 0.00 Digital Reference Frequency P codes: Motor 1 Parameters Change Incre- Data Default Code Name Data setting range Unit when ment...
Page 47 H codes: High Performance Functions Change Incre- Data Default Code Name Data setting range Unit when ment copying setting running Data Initialization 0: Disable initialization – – 1: Initialize all function code data to the factory defaults 2: Initialize motor 1 parameters Auto-reset (Times) 0 (Disable), 1 to 10...
Page 48 – (Anti-regenerative 1: Enable (Lengthen the deceleration time control) to three times the specified time under voltage limiting control.) (Compatible with the original FVR-Micro FVR…AS1S-…) (Mode selection) 4: Enable (Torque limit control: Disable force-to-stop processing.) Overload Prevention 0.00: Follow deceleration time specified by 0.01 Hz/s...
Page 49 (H codes continued) Change Incre- Data Default Code Name Data setting range Unit when ment copying setting running 0: Disable – – Electronic Thermal Overload Protection for 1: Enable Motor (Data retention) PID Feedback Wire 0.0: Disable alarm detection Break Detection 0.1 to 60.0: After the specified time, cause (Terminal [C1]) alarm...
Page 50 J codes: Application Functions Change Incre- Data Default Code Name Data setting range Unit when ment copying setting running PID Control 0: Disable – – (Mode selection) 1: Enable (Process control, normal operation) 2: Enable (Process control, inverse operation) (Remote command SV) 0: UP/DOWN keys on keypad –...
Page 51 Y codes: Link Functions Change Incre- Data Default Code Name Data setting range Unit when ment copying setting running RS-485 Communication 1 1 to 255 – (Station address) 0: Immediately trip with alarm er8 – – (Communications error 1: Trip with alarm er8 after running for the processing) period specified by timer y03 2: Retry during the period specified by timer...
Page 52 Table A Fuji Standard Motor Parameters Restart mode after Fuji's Nominal rated Nominal rated momentary power standard current of capacity of failure torque Fuji standard Fuji standard (Restart time) Applicable boost (%) motor (A) motor (kW) Power motor Inverter type supply rating voltage...
Page 53: Details Of Function Codes
5.2 Details of Function Codes This section provides the details of the function codes frequently used for the FVR-Micro of inverters.  For details about the function codes given below and other function codes not given below. Data Protection F00 specifies whether to protect function code data (except F00) and digital reference data...
Page 54 Data for Function F01, C30 Enable the current input to terminal [C1] (+4 to +20 mA DC or 0 to +20 mA DC, maximum frequency obtained at +20 mA DC).  Using function code C40 expands the input range from "+4 to +20 mA DC" to "0 to +20 mA DC."...
Page 55 Data for F02 Run Command Source Description Keypad Enable keys to run and stop the motor. (Reverse rotation) Note that this run command enables only the reverse rotation. There is no need to specify the rotation direction. • When function code F02 = 0 or 1, the "Run forward" FWD and "Run reverse" REV terminal commands must be assigned to terminals [FWD] and [REV], respectively.
Page 56  Rated Voltage at Base Frequency (F05) Set "0" or the rated voltage printed on the nameplate labeled on the motor. - If "0" is set, the rated voltage at base frequency is determined by the power source of the inverter. The output voltage will vary in line with any variance in input voltage. - If the data is set to anything other than "0,"...
Page 57  V/f pattern with two non-linear points Acceleration Time 1 Deceleration Time 1 Acceleration Time 2 Deceleration Time 2 F07 specifies the acceleration time, the length of time the frequency increases from 0 Hz to the maximum frequency. F08 specifies the deceleration time, the length of time the frequency decreases from the maximum frequency down to 0 Hz.
Page 58 V/f pattern (factory default).  V/f characteristics The FVR-Micro of inverters offers a variety of V/f patterns and torque boosts, which include V/f patterns suitable for variable torque load such as general fans and pumps or for special pump load requiring high starting torque.
Page 59  Torque boost • Manual torque boost (F09) In torque boost using F09, constant voltage is added to the basic V/f pattern, regardless of the load, to give the output voltage. To secure a sufficient starting torque, manually adjust the output voltage to optimally match the motor and its load by using F09.
Page 60 • Auto torque boost This function automatically optimizes the output voltage to fit the motor with its load. Under light load, auto torque boost decreases the output voltage to prevent the motor from over-excitation. Under heavy load, it increases the output voltage to increase output torque of the motor.
Page 61 Cooling Characteristics of Motor with Shaft-driven Cooling Fan Nominal Applied Motor and Characteristic Factors when P99 (Motor 1 selection) = 0 Reference current Output frequency for Characteristic Nominal Thermal time for setting the motor characteristic factor factor constant τ applied motor thermal time (kW) (Factory default)
Page 62  Overload detection level (F11) F11 specifies the detection level (in amperes) at which the electronic thermal overload protection becomes activated. In general, set F11 to the rated current of motor when driven at the base frequency (i.e. 1.0 to 1.1 multiple of the rated current of motor 1 (P03)).
Page 63 Example of Thermal Overload Detection Characteristics Restart Mode after Momentary Power Failure Restart Mode after Momentary Power Failure, Restart time Restart Mode after Momentary Power Failure, Frequency fall rate F14 specifies the action to be taken by the inverter such as trip and restart in the event of a momentary power failure.
Page 64 Data for F14 Mode Descri Trip after decelerate- As soon as the DC link bus voltage drops below to-stop the continuous running level due to a momentary power failure, decelerate-to-shop control is invoked. Decelerate-to-stop control regenerates kinetic energy from the load's moment of inertia, slowing down the motor and continuing the deceleration operation.
Page 65  Restart mode after momentary power failure (Basic operation) The inverter recognizes a momentary power failure upon detecting the condition that DC link bus voltage goes below the under voltage detection level, while the inverter is running. If the load of the motor is light and the duration of the momentary power failure is extremely short, the voltage drop may not be great enough for a momentary power failure to be recognized, and the motor may continue to run uninterrupted.
Page 66 During a momentary power failure, the motor slows down. After power is restored, the inverter restarts at the frequency just before the momentary power failure. Then, the current limiting function works and the output frequency of the inverter automatically decreases. When the output frequency matches the motor speed, the motor accelerates up to the original output frequency.
Page 67  Restart mode after momentary power failure (Frequency fall rate) (H14) During restart after a momentary power failure, if the inverter output frequency and the idling motor speed cannot be harmonized with each other, an overcurrent will flow, activating the overcurrent limiter. If it happens, the inverter reduces the output frequency to match the idling motor speed according to the reduction rate (Frequency fall rate: Hz/s) specified by H14.
Page 68 Bias (Frequency command 1) Bias (for Frequency 1) (Bias base point) C32, C34 Analog Input Adjustment for [12] (Gain, Gain base point) C37, C39 Analog Input Adjustment [C1] (Gain, Gain base point) When any analog input for frequency command 1 (F01) is used, it is possible to define the relationship between the analog input and the reference frequency by multiplying the gain and adding the bias specified by F18.
Page 69 (Point A) To set the reference frequency to 0 Hz for an analog input being at 1 V, set the bias to 0% (F18 = 0). Since 1 V is the bias base point and it is equal to 10% of 10 V (full scale), set the bias base point to 10% (C50 = 10).
Page 70 [Conversion formula] × 100 Setting value (%) = Example: If setting I (A) of 4.2 A with standard applicable motor capacity of 0.75 kW 4.2 (A) × 100 = 84 Setting value (%) = 5.0 (A)  Braking time (F22) F22 specifies the braking period that activates DC braking.
Page 71 Starting Frequency 1 Starting Frequency 1 (Holding time) Stop Frequency Stop Frequency (Holding time) At the startup of an inverter, the initial output frequency is equal to the starting frequency 1 specified by F23. The inverter stops its output when the output frequency reaches the stop frequency specified by F25.
Page 72 F26,F27 Motor Sound (Carrier frequency and tone)  Motor sound (Carrier frequency) (F26) F26 controls the carrier frequency so as to reduce an audible noise generated by the motor or electromagnetic noise from the inverter itself, and to decrease a leakage current from the main output (secondary) wirings.
Page 73 Analog Output [FMA] (Voltage adjustment) Analog Output [FMA] (Function) These function codes allow terminal [FMA] to output monitored data such as the output frequency and the output current in an analog DC voltage. The magnitude of the output voltage is adjustable. ...
Page 74 Control Mode Selection 1 F42 specifies the control mode of the inverter to control a motor. Data for F42 Control mode V/f control with slip compensation inactive Dynamic torque vector control V/f control with slip compensation active  V/f control In this control, the inverter controls a motor by the voltage and frequency according to the V/f pattern specified by function codes.
Page 75 F43,F44 Current Limiter (Mode selection, Level) When the output current of the inverter exceeds the level specified by the current limiter (F44), the inverter automatically manages its output frequency to prevent a stall and limit the output current. (Refer to the description of function code H12.) If F43 = 1, the current limiter is enabled only during constant speed operation.
Page 76 F50,F51 Electronic Thermal Overload Protection for Braking Resistor (Discharging capability and Allowable average loss) A braking resistor can be mounted on inverters of 0.4 kW or above. These function codes specify the electronic thermal overload protection feature for the braking resistor. Set F50 and F51 data to the discharging capability and allowable average loss, respectively.
Page 77  External Braking Resistors Standard models The thermal sensor relay mounted on the braking resistor acts as a thermal protector of the motor for overheat, so assign an "Enable external alarm trip" terminal command THR to any of digital input terminals [X1] to [X3], [FWD] and [REV] and connect that terminal and its common terminal to braking resistor's terminals 2 and 1.
Page 78 E01 to E03 Terminal [X1] to [X3] Function E98, E99 Terminal [FWD] and [REV] Function Function codes E01 to E03, E98 and E99 allow you to assign commands to terminals [X1] to [X3], [FWD], and [REV] which are general-purpose, programmable, digital input terminals. These function codes may also switch the logic system between normal and negative to define how the inverter logic interprets either ON or OFF status of each terminal.
Page 79 Terminal function assignment and data setting  Select multistep frequency (0 to 15 steps) -- SS1, SS2, SS4, and SS8 (Function code data = 0, 1, 2, and 3) The combination of the ON/OFF states of digital input signals SS1, SS2, SS4 and SS8 selects one of 16 different frequency commands defined beforehand by 15 function codes C05 to C19 (Multistep frequency 0 to 15).
Page 80  Enable 3-wire operation -- HLD (Function code data = 6) Turning this terminal command ON self-holds the forward FWD or reverse REV run command issued with it, to enable 3-wire inverter operation. Short-circuiting the terminals between HLD and [CM] (i.e., when HLD is ON) self-holds the first FWD or REV command at its leading edge.
Page 81  Ready for jogging -- JOG (Function code data = 10) This terminal command is used to jog or inch the motor for positioning a work piece. Turning this command ON makes the inverter ready for jogging. Simultaneous keying keys on the keypad is functionally equivalent to this command; however, it is restricted by the run command source as listed below.
Page 82  Enable DC braking -- DCBRK (Function code data = 13) This terminal command gives the inverter a DC braking command through the inverter’s digital input.(Refer to the descriptions of F20 to F22.)  UP (Increase output frequency) and DOWN (Decrease output frequency) commands -- UP and DOWN (Function code data = 17, 18) •...
Page 83 The UP/DOWN control is available in two modes--one mode (H61 = 0) in which the initial value of the reference frequency is fixed to "0.00" at the start of the UP/DOWN control and the other mode (H61 = 1) in which the reference frequency applied in the previous UP/DOWN control applies as the initial value.
Page 84  Enable communications link via RS-485 -- LE (Function code data = 24) Turning this terminal command ON assigns priorities to frequency commands or run commands received via the RS-485 communications link (H30). No LE assignment is functionally equivalent to the LE being ON. (Refer to the description of H30.) ...
Page 85 The table below lists functions that can be assigned to terminals [Y1] and [30A/B/C]. To make the explanations simpler, the examples shown below are all written for the normal logic (Active ON). Function code data Functions assigned Symbol Active ON Active OFF 1000 Inverter running...
Page 86  Frequency detected -- FDT (Function code data = 2) This output signal comes ON when the output frequency exceeds the frequency detection level specified by E31, and it goes OFF when the output frequency drops below the "Frequency detection level (E31) - Hysteresis width (E32)."...
Page 87  Inverter running 2 -- RUN2 (Function code data = 35) This signal acts in the same way as RUN (Function code data = 0) except that RUN2 is ON even when the DC braking is in operation.  Overload prevention control -- OLP (Function code data = 36) This output signal comes ON when the overload prevention control is activated.
Page 88  Motor overheat detected by thermistor (PTC) -- THM (Function code data = 56) When the thermistor is enabled (H26 = 2), this output signal comes ON if the motor temperature rises to the protection trigger level specified by H27. ...
Page 89 Motor Thermal time Data Detection level Timer characteristics constant assigned Output to output signal Range: Range: Range: Range: terminal 0.5 to 75.0 min See below 0.01 to 600.00 s See below - Data setting range Operation level: 0.00 (Disable), 1 to 200% of inverter rated current Motor characteristics 1: Enable (For a general-purpose motor and Fuji standard permanent magnet synchronous motor with shaft-driven cooling fan) 2: Enable (For an inverter-driven motor with separately powered...
Page 90  Low current detected -- IDL This signal turns ON when the output current drops below the low current detection level (E34) and remains at the low level for the timer period (E35). When the output current exceeds the "Low current detection level plus 5% of the inverter rated current," it goes OFF. (The minimum ON-duration is 100 ms.) Coefficient for Constant Feeding Rate Time Coefficient for Speed Indication...
Page 91 Built-in Potentiometer (Function selection) Terminal [12] Extended Function Terminal [C1] Extended Function E60 through E62 define the property of the built-in potentiometer and terminals [12] and [C1], respectively. There is no need to set up the potentiometer and terminals if they are to be used for frequency command sources.
Page 92 Operating procedure for timer operation (example) Preparation • To display the timer count on the LED monitor, set E43 (LED Monitor) to "13" (Timer) and set C21 (Timer Operation) to "1" (Enable). • Specify the reference frequency to apply to timer operation. When the keypad is selected as a frequency command source, press the key to shift to the speed monitor and specify the desired reference frequency.
Page 93 Motor 1 (Auto-tuning) The inverter automatically detects the motor parameters and saves them in its internal memory. Basically, it is not necessary to perform tuning when using a Fuji standard motor with a standard connection with the inverter. In any of the following cases, perform auto-tuning since the motor parameters are different from those of Fuji standard motors so as not to obtain the best performance under each of these controls-- auto torque boost, torque calculation monitoring, auto energy saving operation, automatic deceleration (anti-regenerative control), slip compensation, and torque...
Page 94  Rated slip frequency (P12) Convert the value obtained from the motor manufacturer to Hz using the following expression and enter the converted value. (Note: The motor rating given on the nameplate sometimes shows a larger value.) (Synchronous speed - Rated speed) Rated slip frequency (Hz) = x Base frequency Synchronous speed...
Page 95 Data Initialization H03 initializes the current function code data to the factory defaults or initializes the motor parameters. To change the H03 data, it is necessary to press the keys or keys(simultaneous keying). Data for H03 Function Disable initialization (Settings manually made by the user will be retained.) Initialize all function code data to the factory defaults Initialize motor 1 parameters in accordance with P02 (Rated capacity) and P99 (Motor 1 selection)
Page 96 H04,H05 Auto-reset (Times and Reset interval) H04 and H05 specify the auto-reset function that makes the inverter automatically attempt to reset the tripped state and restart without issuing an alarm (for any faults) even if any protective function subject to reset is activated and the inverter enters the forced-to-stop state (tripped state).
Page 97 Cooling Fan ON/OFF Control To prolong the life of the cooling fan and reduce fan noise during running, the cooling fan stops when the temperature inside the inverter drops below a certain level while the inverter stops. However, since frequent switching of the cooling fan shortens its life, the cooling fan is kept running for 10 minutes once it is started.
Page 98 Acceleration/deceleration time <S-curve acceleration/deceleration (weak): when the frequency change is 10% or more of the maximum frequency> Acceleration or deceleration time (s) = (2 x 5/100 + 90/100+ 2 x 5/100) x (reference acceleration or deceleration time) = 1.1 x (reference acceleration or deceleration time) <S-curve acceleration/deceleration (strong): when the frequency change is 20% or more of the maximum frequency>...
Page 99 Instantaneous Overcurrent Limiting (Mode selection) H12 specifies whether the inverter invokes the current limit processing or enters the overcurrent trip when its output current exceeds the instantaneous overcurrent limiting level. Under the current limit processing, the inverter immediately turns OFF its output gate to suppress the further current increase and continues to control the output frequency.
Page 100 When H69 = 1: The anti-regenerative control is functionally equivalent to that of the original FVR-Micro. That is, when the DC link bus voltage exceeds the preset voltage limiting level, the inverter lengthens the deceleration time to three times the specified time to decrease the deceleration torque to 1/3.
Page 101 Data for H69 Function Disable Enable (Lengthen the deceleration time to three times the specified time under voltage limiting control.) Enable (Torque limit control: Disable force-to-stop processing.) Enabling the anti-regenerative control may automatically increase the deceleration time. When a braking resistor is connected, disable the anti-regenerative control. Automatic Overload Prevention Control H70 specifies the decelerating rate of the output frequency to prevent a trip from occurring due to an overload.
Page 102 Cumulative Run Time of Motor 1 Operating the keypad can display the cumulative run time of motor 1. This feature is useful for management and maintenance of the machinery. Using H94 can modify the cumulative run time of the motor to the desired value to be used as an arbitrary initial data. Specifying "0" clears the cumulative run time.
Page 103: Chapter 6 Troubleshooting
Chapter 6 TROUBLESHOOTING 6.1 If an Alarm Code Appears on the LED Monitor Quick reference table of alarm codes Alarm Alarm Name Name code code Braking resistor overheated Motor 1 overload Instantaneous overcurrent Motor 2 overload Inverter overload Memory error Overvoltage Keypad communications error CPU error...
Page 104: Monitor While No Alarm Code Is Displayed
6.2 If an Abnormal Pattern Appears on the LED Monitor while No Alarm Code is Displayed [ 1 ] – – – – (center bar) appears Problem A center bar (– – – –) has appeared on the LED monitor. Possible Causes What to Check and Suggested Measures (1) When the PID command...
Page 105 [ 3 ] appears Problem Parentheses ( ) appeared on the LED monitor during speed monitoring on the keypad. Possible Causes What to Check and Suggested Measures (1) The display data Check whether the product of the output frequency and the overflows the LED display coefficient (E50) exceeds 9999.
Page 106: Chapter 7 Maintenance And Inspection
Chapter 7 MAINTENANCE AND INSPECTION Perform daily and periodic inspection to avoid trouble and keep reliable operation of the inverter for a long time. When performing inspections, follow the instructions given in this chapter. • Before proceeding to the maintenance and inspection, turn OFF the power and wait at least five minutes.
Page 107 Table 7.1 List of Periodic Inspections (Continued) Check part Check item How to inspect Evaluation criteria 1) Check that the display is clear. 1), 2) 1), 2) Keypad 2) Check that there is no missing part Visual inspection The display can in the displayed characters.
Page 108: Standard Lifetime Of Parts
Table 7.1 List of Periodic Inspections (Continued) Check part Check item How to inspect Evaluation criteria 1) Check for chatters during 1) Hearing 1), 2) Magnetic operation. inspection contactor No abnormalities and relay 2) Check for rough contacts. 2) Visual inspection 1) Check for loose screws and 1) Retighten.
Page 109: Inquiries About Product And Guarantee
7.4 Inquiries about Product and Guarantee 7.4.1 When making an inquiry Upon breakage of the product, uncertainties, failure or inquiries, inform your Fuji electric Co., Ltd. representative of the following information. 1) Inverter type (Refer to Chapter 1, Section 1.1.) 2) SER No.
Page 110 (2) Warranty range 1) In the event that breakdown occurs during the product's warranty period which is the responsibility of Fuji Electric Co., Ltd., Fuji Electric Co., Ltd. will replace or repair the part of the product that has broken down free of charge at the place where the product was purchased or where it was delivered.
Page 111 [ 3 ] Repair period after production stop, spare parts supply period (holding period) Concerning models (products) which have gone out of production, this company will perform repairs for a period of 7 years after production stop, counting from the month and year when the production stop occurs.
Page 112: Chapter 8 Specifications
Chapter 8 SPECIFICATIONS 8.1 Standard Models 8.1.1 Single-phase 200 V class series Item Specifications 0.75 Type Applicable motor rating (kW) 0.75 Rated capacity (kVA) Rated voltage (V) *3 Three-phase, 200 to 240 V (with AVR function) Rated current (A) *4 3.5 (2.5) 4.2 (4.2) 9.2 (7.5)
Page 113: Three-Phase 400 V Class Series
8.1.2 Three-phase 400 V class series Item Specifications Type 0.75 Applicable motor rating (kW) 0.75 Rated capacity (kVA) Rated voltage (V) *3 Three-phase, 380 to 480 V (with AVR function) 10.5 Rated current (A) (1.5) (2.5) (4.2) (5.5) (9.0) 150% of rated output current for 1 min (for the rated current given in parentheses) Overload capability Rated frequency (Hz)
Page 114: Terminal Specifications
8.2 Terminal Specifications 8.2.1 Terminal functions For details about the main and control circuit terminals, refer to Chapter 2, Section 2.3.5 and Section 2.3.6 (Table 2.7), respectively. 8.2.2 Connection diagram in operation by external signal inputs DBR (Dynamic Braking Resistor) MCCB or RCD/ELCB MC (Note 2)
Page 115 (Note 6) For the wiring of the control circuit, use shielded or twisted wires. When using shielded wires, connect the shields to earth. To prevent malfunction due to noise, keep the control circuit wiring away from the main circuit wiring as far as possible (recommended: 10 cm or longer), and never set them in the same wire duct.
Page 116: Protective Functions
8.3 Protective Functions "—": Not applicable. Alarm Name Description monitor output displays [30A,B,C] Overcurrent - Stops the inverter output to protect the During protection inverter from an overcurrent resulting from acceleration overload. Short-circuit During protection - Stops the inverter output to protect the deceleration inverter from an overcurrent due to a short Ground fault...
Page 117 Alarm monitor output Name Description displays [30A,B,C] Electronic Stops the inverter output in accordance with the setting of the thermal electronic thermal overload relay to protect the motor. overload This function protects general-purpose motors and inverter motors relay over the entire frequency range, as well as protecting the 2nd motor.
Page 118 Alarm Name Description monitor output displays [30A,B,C] Tuning error *1 Stops the inverter output when a tuning failure, interruption, or abnormal tuning result is detected during tuning of motor parameters. RS-485 Upon detection of an RS-485 communications error, the inverter communication stops its output.
Page 119: External Dimension
8.4 External Dimensions [unit: mm] [FVR0.4AS1S-7/FVR0.75AS1S-7] [FVR1.5AS1S-7/FVR2.2AS1S-7/ FVR0.4AS1S-4~FVR2.2AS1S-4] [FVR3.7AS1S-4]...
Page 120: Conformity To The Low Voltage Directive In The Eu
Chapter 9 COMPLIANCE WITH STANDARDS 9.1 Conformity to the Low Voltage Directive in the EU If installed according to the guidelines given below, inverters marked with CE are considered as compliant with the Low Voltage Directive in Europe. 1. The ground terminal G should always be connected to the ground.
Page 121 9.1 Conformity to the Low Voltage Directive in the EU (Continued) Use wires listed in IEC60364-5-52. Recommended wire size (mm Main circuit Appli- power input cable Control circuit [L1/R, L2/S, motor Inverter type (30A, Braking resistor Inverter output L3/T] rating 30B, [P, DB] [U, V, W]...
Page 122: Conformity With Ul Standards And Cul-Listed For Canada
9.1 Conformity to the Low Voltage Directive in the EU (Continued) To prevent the risk of hazardous accidents that could be caused by damage of the inverter, install the specified fuses in the supply side (primary side) according to the following tables. - Breaking capacity: Min.
Page 123 9.2 Conformity with UL standards and cUL-listed for Canada (Continued) Short circuit rating When protected by a circuit breaker, suitable for use on a circuit capable of delivering not more than B rms symmetrical amperes, A volts maximum. ■kW rating Power supply Inverter type...
Page 124 9.2 Conformity with UL standards and cUL-listed for Canada (Continued) 5. Install UL certified circuit breaker rated 240V or more for 200V input, 480V or more for 400V input, between the power supply and the inverter, referring to the table below. Required torque Wire size Ib-in (N･m)
Page 125 9.2 Conformity with UL standards and cUL-listed for Canada (Continued) 6. To comply with CSA for 200 VAC input models, transient surge suppression shall be installed on the line side of this equipment and shall be rated 240 V (phase to ground), 240 V (phase to phase), suitable for overvoltage category 3, and shall provide protection for a rated impulse withstand voltage peak of 4 kV.
Page 126 installation MCCB or Metal panel RCD/ELCB (Note 2) (Note 1) Power N-Micro supply L1/R (L1/L) EMC- compliant L2/S filter (optional) L3/T (L2/N) Three- Motor single- phase (Note 3) Shielded * with overcurrent protection (Note 3) cable Figure 10.1 Installing the Inverter with EMC-compliant Filter into a Metal Panel Note 1: Pass the EMC filter input wires (shielded cable and grounding wire in a bundle) through the ferrite bead core for reducing radio noise two times.
Page 127 The purpose of this instruction manual is to provide accurate information in handling, setting up and operating of the FVR-Micro of inverters. Please feel free to send your comments regarding any errors or omissions you may have found, or any suggestions you may have for generally improving the manual.
Page 128 Fuji Electric Co., Ltd. Gate City Ohsaki, East Tower, 11-2, Osaki 1-chome, Shinagawa-ku, Tokyo 141-0032, Japan Phone: +81-3-5435-7058 Fax: +81-3-5435-7420 h t t p : / / w w w . f u j i e l e c t r i c . c o m 2017-09 (F13a/C13)
