Troubleshooting
Bit (Hex)
00000001
00000002
00000004
00000008
00000010
00000020
00000040
00000080
00000100
00000200
00000400
00000800
00001000
00002000
00004000
00008000
Table 10.18 FC 102/FC 202/FC 301/FC 302/FCD 302
Bit (Hex)
00000001
00000002
00000004
10
10
00000008
00000010
00000020
00000040
00000080
00000100
00000200
00000400
00000800
00001000
00002000
00004000
00008000
Table 10.19 FC 102/FC 202/FC 301/FC 302/FCD 302
NOTICE
16-84 Comm. Option STW is not part of extended
diagnosis.
68
Unit
PROFIBUS warning word
diagnose
(9-53 Profibus Warning Word)
bit
160
Connection with DP-master is not ok
161
Unused
162
FDL (Fieldbus Data link Layer) is not ok
163
Clear data command received
164
Actual value is not updated
165
Baudrate search
166
PROFIBUS ASIC is not transmitting
167
Initialising of PROFIBUS is not ok
152
Drive is tripped
153
Internal CAN error
154
Wrong configuration data from PLC
155
Wrong ID sent by PLC
156
Internal error occurred
157
Not configured
158
Timeout active
159
Warning 34 active
Comm. option STW (16-84 Comm. Option STW)
parameterization ok
configuration ok
clearmode active
baudrate search
waiting for parameterization
waiting for configuration
in data exchange
not used
not used
not used
not used
MCL2/1 connected
MCL2/2 connected
MCL2/3 connected
data transport active
not used
Danfoss A/S © Rev. 2014-02-27 All rights reserved.
Operating Instructions
10.6 Warning and Alarm Messages
There is a clear distinction between alarms and warnings.
An alarm make the frequency converter enter a fault
condition. After the cause for the alarm has been cleared,
the master will have to acknowledge the alarm message
before the frequency converter can start operating again.
A warning condition triggers a warning which disappears
when condition returns to normal, without interfering with
the process.
Warnings
A single bit within a warning word represents warnings
within the frequency converter. Bit status [0] False means
no warning, while bit status [1] True means warning. Any
bit change in the warning word is notified by a change of
bit 7 in the status word.
Alarms
Following an alarm message, the frequency converter
enters fault condition. When the fault has been removed
and the controller has acknowledged the alarm message
by setting bit 7 in the control word, the frequency
converter resumes operation. A single bit within an alarm
word represents alarms within the frequency converter. Bit
status [0] False means no fault, while bit status [1] True
means fault.
MG90U302
