Parameters
9-23 Parameters for Signals
Array [1000]
Read only
Option:
[1655] Feedback 2 [Unit]
[1656] Feedback 3 [Unit]
[1660] Digital Input
[1661] Terminal 53 Switch Setting
[1662] Analog Input 53
[1663] Terminal 54 Switch Setting
[1664] Analog Input 54
[1665] Analog Output 42 [mA]
[1666] Digital Output [bin]
[1667] Pulse Input #29 [Hz]
[1668] Pulse Input #33 [Hz]
[1669] Pulse Output #27 [Hz]
[1670] Pulse Output #29 [Hz]
[1671] Relay Output [bin]
[1672] Counter A
8 8
[1673] Counter B
[1675] Analog In X30/11
[1676] Analog In X30/12
[1677] Analog Out X30/8 [mA]
[1680] Fieldbus CTW 1
[1682] Fieldbus REF 1
[1684] Comm. Option STW
[1685] FC Port CTW 1
[1690] Alarm Word
[1691] Alarm Word 2
[1692] Warning Word
[1693] Warning Word 2
[1694] Ext. Status Word
[1695] Ext. Status Word 2
[1696] Maintenance Word
[1840] Analog Input X49/1
[1841] Analog Input X49/3
[1842] Analog Input X49/5
[1843] Analog Out X49/7
[1844] Analog Out X49/9
[1845] Analog Out X49/11
[1846] X49 Digital Output [bin]
[2013] Minimum Reference/Feedb.
[2014] Maximum Reference/Feedb.
[2021] Setpoint 1
[2022] Setpoint 2
[2023] Setpoint 3
[3644] Terminal X49/7 Bus Control
[3654] Terminal X49/9 Bus Control
[3664] Terminal X49/11 Bus Control
48
Operating Instructions
Function:
[0] Disabled Disables editing via PROFINET.
[1] Enabled Enables editing via PROFINET.
[0] Disable
[1] Enable
0
Read only
Bit
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
Danfoss A/S © Rev. 2014-02-27 All rights reserved.
9-27 Parameter Edit
Option: Function:
Parameters can be edited via PROFINET, the
standard RS-485 interface, or the LCP.
9-28 Process Control
Option: Function:
Process control (setting of Control Word, speed
reference, and process data) is possible via either
PROFINET or standard fieldbus but not both
simultaneously. Local control is always possible via
the LCP. Control via process control is possible via
either terminals or fieldbus depending on the
settings in parameter 8-50 Coasting Select to
8-56 Preset Reference Select.
Disables process control via PROFINET, and enables
process control via standard fieldbus or PROFINET
IO-Supervisor.
Enables process control via IO Controller, and
cyclic disables process control via standard fieldbus or
master PROFINET IO-Supervisor..
9-53 Profibus Warning Word
Range: Function:
[0 - 65535 ] This parameter displays PROFINET communi-
*
cation warnings.
Condition when bit is active
Connection with IO Controller is not ok
Reserved for status of connection with second IO
Controller
Not used
Clear data command received
Actual value is not updated
No Link on both port
Not used
Initializing of PROFINET is not ok
Drive is tripped
Internal CAN error
Wrong configuration data from IO Controller
Not used
Internal error occurred
Not configured
Timeout active
Warning 34 active
Table 8.1 PROFINET Communication Warnings
