Parameters
9-65 Profile Number
Range: Function:
0 [0 - 0 ] This parameter contains the profile identification.
*
Byte 1 contains the profile number and byte 2 the
version number of the profile.
NOTICE
This parameter is not visible via LCP.
9-70 Programming Set-up
Option: Function:
Select the set-up to be edited.
[0] Factory setup Uses default data. This option can be used as
a data source to return the other set-ups to a
known state.
[1] Set-up 1 Edits Set-up 1.
[2] Set-up 2 Edits Set-up 2.
[3] Set-up 3 Edits Set-up 3.
[4] Set-up 4 Edits Set-up 4.
[9] Active Set-up Follows the active set-up selected in
0-10 Active Set-up.
This parameter is unique for LCP and fieldbuses. See
0-11 Programming Set-up.
9-71 Profibus Save Data Values
Option: Function:
Parameter values changed via PROFINET are not
automatically stored in non-volatile memory. Use
this parameter to activate a function that stores
parameter values in the EEPROM non-volatile
memory, so changed parameter values will be
retained at power-down.
[0] Off Deactivates the non-volatile storage function.
[1] Store all Stores all parameter values for all set-ups in the
setups non-volatile memory. The selection returns to [0]
Off when all parameter values have been stored.
[2] Store all Stores all parameter values for all set-ups in the
setups non-volatile memory. The selection returns to [0]
Off when all parameter values have been stored.
9-72 ProfibusDriveReset
Option: Function:
[0] No action
[1] Power-on Resets frequency converter upon power-up, as
reset for power-cycle.
[3] Comm Resets the PROFINET option only, the
option reset PROFINET option goes through a power-up
sequence.
When reset, the frequency converter
disappears from the fieldbus, which may
cause a communication error from the master.
MG90U302
Operating Instructions
9-80 Defined Parameters (1)
Array [116]
No LCP access
Read only
Range:
0 [0 - 9999 ] This parameter displays a list of all the defined
*
9-81 Defined Parameters (2)
Array [116]
No LCP access
Read only
Range:
0 [0 - 9999 ] This parameter displays a list of all the defined
*
9-82 Defined Parameters (3)
Array [116]
No LCP access
Read only
Range:
0 [0 - 9999 ] This parameter displays a list of all the defined
*
9-83 Defined Parameters (4)
Array [116]
No LCP access
Read only
Range:
0 [0 - 9999 ] This parameter displays a list of all the defined
*
9-84 Defined Parameters (5)
Array [115]
No LCP access
Read only
Range:
0 [0 - 9999 ] This parameter displays a list of all the defined
*
9-90 Changed Parameters (1)
Array [116]
No LCP access
Read only
Range:
0 [0 - 9999 ] This parameter displays a list of all the
*
Danfoss A/S © Rev. 2014-02-27 All rights reserved.
Function:
frequency converter parameters available for
PROFINET.
Function:
frequency converter parameters available for
PROFINET.
Function:
frequency converter parameters available for
PROFINET.
Function:
frequency converter parameters available for
PROFINET.
Function:
frequency converter parameters available for
PROFINET.
Function:
frequency converter parameters deviating from
default setting.
8 8
