Parameters
8-13 Configurable Status Word STW
Option:
[2] Alarm 68 Only
[3] Trip excl.
Alarm 68
[10] T18 DI status.
[11] T19 DI status.
[12] T27 DI status.
[13] T29 DI status.
[14] T32 DI status.
8 8
[15] T33 DI status.
[16] T37 DI status
[21] Thermal
warning
[30] Brake fault
(IGBT)
[40] Out of ref.
range
[60] Comparator 0
[61] Comparator 1
[62] Comparator 2
[63] Comparator 3
[64] Comparator 4
[65] Comparator 5
44
Operating Instructions
Function:
Only set in case of an Alarm 68.
Set in case of a trip, except if Alarm 68
executes the trip.
The bit indicates the status of terminal 18.
"0" indicates that the terminal is low
"1" indicates that the terminal is high
The bit indicates the status of terminal 19.
"0" indicates that the terminal is low
"1" indicates that the terminal is high
The bit indicates the status of terminal 27.
"0" indicates that the terminal is low
"1" indicates that the terminal is high
The bit indicates the status of terminal 29.
"0" indicates that the terminal is low
"1" indicates that the terminal is high
The bit indicates the status of terminal 32.
"0" indicates that the terminal is low
"1" indicates that the terminal is high
The bit indicates the status of terminal 33.
"0" indicates that the terminal is low
"1" indicates that the terminal is high
The bit indicates the status of terminal 37.
"0" indicates T37 is low (safe stop)
"1" indicates T37 is high (normal)
The thermal warning turns on when the
temperature exceeds the limit in the
motor, the frequency converter, the brake
resistor, or the thermistor.
Output is Logic '1' when the brake IGBT is
short-circuited. Use this function to protect
the frequency converter if there is a fault
on the brake modules. Use the output/
relay to cut out the main voltage from the
frequency converter.
See parameter group 13-1* Comparators. If
Comparator 0 is evaluated as TRUE, the
output goes high. Otherwise, it is low.
See parameter group 13-1* Comparators. If
Comparator 1 is evaluated as TRUE, the
output goes high. Otherwise, it is low.
See parameter group 13-1* Comparators. If
Comparator 2 is evaluated as TRUE, the
output goes high. Otherwise, it is low.
See parameter group 13-1* Comparators. If
Comparator 3 is evaluated as TRUE, the
output goes high. Otherwise, it is low.
See parameter group 13-1* Comparators. If
Comparator 4 is evaluated as TRUE, the
output goes high. Otherwise, it is low.
See parameter group 13-1* Comparators. If
Comparator 5 is evaluated as TRUE, the
output goes high. Otherwise, it is low.
Danfoss A/S © Rev. 2014-02-27 All rights reserved.
8-13 Configurable Status Word STW
Option: Function:
[70] Logic Rule 0 See parameter group 13-4* Logic Rules. If
Logic Rule 0 is evaluated as TRUE, the
output goes high. Otherwise, it is low.
[71] Logic Rule 1 See parameter group 13-4* Logic Rules. If
Logic Rule 1 is evaluated as TRUE, the
output goes high. Otherwise, it is low.
[72] Logic Rule 2 See parameter group 13-4* Logic Rules. If
Logic Rule 2 is evaluated as TRUE, the
output goes high. Otherwise, it is low.
[73] Logic Rule 3 See parameter group 13-4* Logic Rules. If
Logic Rule 3 is evaluated as TRUE, the
output goes high. Otherwise, it is low.
[74] Logic Rule 4 See parameter group 13-4* Logic Rules. If
Logic Rule 4 is evaluated as TRUE, the
output goes high. Otherwise, it is low.
[75] Logic Rule 5 See parameter group 13-4* Logic Rules. If
Logic Rule 5 is evaluated as TRUE, the
output goes high. Otherwise, it is low.
[80] SL Digital See 13-52 SL Controller Action. The output
Output A goes high whenever the Smart Logic
Action [38] Set digital out A high is
executed. The output goes low whenever
the Smart Logic Action [32] Set digital out
A low is executed.
[81] SL Digital See 13-52 SL Controller Action. The input
Output B goes high whenever the Smart Logic
Action [39] Set digital out B high is
executed. The input goes low whenever
the Smart Logic Action [33] Set digital out B
low is executed.
[82] SL Digital See 13-52 SL Controller Action. The input
Output C goes high whenever the Smart Logic
Action [40] Set digital out C high is
executed. The input goes low whenever
the Smart Logic Action [34] Set digital out
C low is executed.
[83] SL Digital See 13-52 SL Controller Action. The input
Output D goes high whenever the Smart Logic
Action [41] Set digital out D high is
executed. The input goes low whenever
the Smart Logic Action [35] Set digital out
D low is executed.
[84] SL Digital See 13-52 SL Controller Action. The input
Output E goes high whenever the Smart Logic
Action [42] Set digital out E high is
executed. The input goes low whenever
the Smart Logic Action [36] Set digital out E
low is executed.
[85] SL Digital See 13-52 SL Controller Action. The input
Output F goes high whenever the Smart Logic
Action [43] Set digital out F high is
executed. The input goes low whenever
the Smart Logic Action [37] Set digital out F
low is executed.
