USB
Phonebook management
SIM application toolkit
Real Time Clock
Timer function
Physical characteristics
PCM
(SIM5320AL only)
Firmware upgrade
Temperature range
2

Package Information

2.1

Pin Configuration

All hardware interfaces which connect SIM5320AL to customers' application platform are through 80 pins
pads (Metal half hole). Figure 2 is SIM5320AL outline diagram.
SIM5320AL_User Manual_V1.01
Support USB2.0 Slave mode
Support phonebook types: SM, FD, LD, RC, ON, MC.
Support SAT class 3, GSM 11.14 Release 98
Support USAT
Support RTC
Programmable by AT command
Size:30*30*2.9mm
Weight:5.6g
Multiplex on GPIOs. 3 kinds of coding formats: 8 bit (-law or A-law)
and 16 bit (linear).
Firmware upgrade over USB interface
Operation temperature: -30°C to +80°C
●
Storage temperature -40°C to +85°C
●
