Package Information; Pin Assignment Overview - SimCom SIM7020C Hardware Design

2

Package Information

2.1

Pin Assignment Overview

1
UART1_TXD
2
UART1_RXD
3
UART1_RTS
4
UART1_CTS
5
UART1_DCD
6
UART1_DTR
7
UART1_RI
8
GND
9
VDD_3V3
10
GPIO0
11
RTC_GPIO0
12
RTC_EINT
SIM7020_Hardware_Design_V1.02
SIM7020
TOP VIEW
Figure 2: Pin assignment overview
10
Smart Machine Smart Decision
33
GND
32
ANT
31
GND
30
GND
29
GPIO1
28
RESET
27
GND
26
USB_DM
25
USB_DP
24
USB_VBUS
23
UART2_RXD
22
UART2_TXD
