PCM_SYNC/GPIO2
PCM_CLK/GPIO3
PCM_DOUT/GPIO5
GPIOs
GPIO1
GPIO4
GPIO40
GPIO41
GPIO43
GPIO44
GPIO42
Other interface
RESET
CURRENT_SINK
ADC1
ADC2
MAIN_ANT
2.3

Package Dimensions

The following figure shows mechanical dimensions of SIM5320AL.
SIM5320AL_User Manual_V1.01
General Input PIN. It also can be
I
multiplexed as the PCM_SYNC pin.
General Output PIN. It also can be
O
multiplexed as the PCM_CLK pin.
General Output PIN. It also can be
O
multiplexed as the PCM_DOUT pin.
Output PIN as LED control for
O
network status.
I Input PIN as RF operating control.
Output PIN as operating status
O
indicating of module.
General input/output PIN. It can be
I/O used as wake/interrupt signal to host
from module
General input/output PIN. It can be
I/O used as wake/interrupt signal to
module from host.
I/O General input/output PIN.
I/O General input/output PIN.
I System reset in, active low.
Current source of ground-referenced
I
current sink
I Analog Digital Converter Input
I Battery temperature ADC input pin
I/O ANT soldering pad
Smart Machine Smart Decision
19
If it is unused, keep open.
Refer to 3.13.1
Refer to 3.13.3
