43 GND
45 NC
47 NC
49 NC
51 NC

3. Package Information

The Mini PCIe Adapter adopts a standard Mini PCI Express connector that has 52 pins and complies with the PCI
Express Mini Card Electromechanical Specification Revision 1.2.
3.1

Pin Out Diagram

The following figure shows the PIN sequence of SIM7200:
SIM7200-PCIe_ Hardware_Design _V1.01
- Ground
- Not connected
- Not connected
- Not connected
- Not connected

Figure 3: SIM7200-PCIe pin out Diagram

44 GPIO7 I/O
46 GPIO6 I/O
48 NC -
50 GND -
52 VCC I
16
Smart Machine Smart Decision
module's status indication
General purpose
input/output
General purpose
input/output
Not connected
Ground
3.3V supply
2016-05-19
