3 Package Information

3.1

Pin out Diagram

3.2

Pin Description

Table 3: Pin description
Pin name
Pin number
Power supply
VCC
6
SIM68R_Hardware Design_V1.02
Figure 2: SIM68R pin out diagram (Top view)
I/O
Description
Main power input, which will be used
I
to power the baseband and RF section
internally.
12
Smart Machine Smart Decision
Comment
Provide clean and stable
power source to this pin.
Add a 4.7uF capacitor to
this pin for decoupling.
2013-01-22
