3.6.1

Pin Description

Table 17: Pin description
Pin name Pin No.
I2C_SDA 56
I2C_SCL 55
3.6.2

Signal Description

Both SDA and SCL are bidirectional lines, connected to a positive supply via a pull-up resistor
respectively. When the bus is free, both lines are high.
3.6.3

Design Guide

For SIM5320AL, the data on the I2C bus can be transferred at rates up to 400kbps. The number of
peripheral devices connected to the bus is solely dependent on the bus capacitance limit of 400pF. Note
that PCB traces length and bending are in users' control to minimize load capacitance.
Note ： I2C_SDA and I2C _SCL have been pulled up with two 2.2kR resistors to 2.6V level in module. So there is no need
to pull them up in users' application circuit.
3.7

Keypad Interface

SIM5320AL module provides a keypad interface that supports five sense lines, or columns, and five
keypad rows. The interface generates an interrupt when any key is pressed. Its operation voltage is 1.8V.
3.7.1 Pin Description
Table 18: Pin description
Pin name Pin No.
KEYSENSE_N0 28
KEYSENSE_N1 27
KEYSENSE_N2 31
KEYSENSE_N3 32
KEYSENSE_N4 36
SIM5320AL_User Manual_V1.01
Function
Serial interface data input and output
Serial interface clock input
Function
Sensing keys
