Smart Module
SIMT 1502
________________________________________________________________
Hardware Version: V1.2
Software Version:CB03_8909_V4.4_20160901
Manufacturer
SHANGHAI SIMCOM LIMITED
Building A,SIM Technology Building,No.633,
District
Expert Importers: Datalogic Srl
Address:
Via San Vitalino 13 – 40012 Lippo di Calderara di Reno
Jinzhong
Road, Changning
Advertisement
Table of Contents
Related Manuals for SimCom SIMT 1502
Summary of Contents for SimCom SIMT 1502
- Page 1 Smart Module SIMT 1502 ________________________________________________________________ Hardware Version: V1.2 Software Version:CB03_8909_V4.4_20160901 Manufacturer SHANGHAI SIMCOM LIMITED Building A,SIM Technology Building,No.633, Jinzhong Road, Changning District Expert Importers: Datalogic Srl Address: Via San Vitalino 13 – 40012 Lippo di Calderara di Reno...
- Page 2 SHANGHAI SIMCOM LIMITED This device is restricted to indoor operation only in the band 5150 - 5350 MHz. (Only for devices that support 802.11 5 GHz functions) This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 3 SHANGHAI SIMCOM LIMITED (1)the device for operation in the band 5150-5250 MHz is only for indoor use to reduce the potential for harmful interference to co-channel mobile satellite systems; (2)the maximum antenna gain permitted for devices in the bands 5250-5350 MHz and 5470-5725 MHz shall comply with the e.i.r.p. limit; and (3)the maximum antenna gain permitted for devices in the band 5725-5850 MHz shall comply with the e.i.r.p.
-
Page 4: Table Of Contents
SHANGHAI SIMCOM LIMITED Contents _____________________________________________________________________________ 1 Introduction ..................................6 1.1 Documentation overview ............................. 6 1.2 Key features ................................6 1.2.1 Feature introduction ..........................6 1.2.2 Summary of features ..........................6 1.3 Block diagram ............................... 8 1.4 Terms and acronyms ............................9 2 Interface Definitions ................................ - Page 5 SHANGHAI SIMCOM LIMITED 4.13 Other interface ..............................29 4.13.1 Camera flash Signal ..........................29 4.13.2 PM_VIB_DRV_N Signal ........................29 4.13.3 VCOIN Signal ............................29 4.13.4 RF Signal input port ..........................30 5 Mechanical Specification ..............................31 5.1 Overview ................................31 5.2 SIMT1502 specifications ............................
-
Page 6: Introduction
SHANGHAI SIMCOM LIMITED 1 Introduction 1.1 Documentation overview This document describes electrical specifications, RF specifications, function interface, mechanical information and testing conclusions of the SIMT1502. With the help of this document, the users can easily and quickly use SIMT1502 on their own applications. - Page 7 SHANGHAI SIMCOM LIMITED ■Encode: H.264 BP/MP Video applications performance – HD(720p),30 fps MPEG-4 SP/H.263P0 –WVGA, 30 fps – WVGA, 30 fps ■ Encode: H.264 BP/MP/HP – 1080p, 30 fps MPEG-4 SP/ASP – 1080p, 30 fps DivX 4x/5x/6x – 1080p, 30 fps H.263 P0...
-
Page 8: Block Diagram
SHANGHAI SIMCOM LIMITED 1.3 Block diagram GPIO28/SCAM_RST_N MIPI FOR GPIO27/SCAM_MCLK JTAG VREG_L11_2P95V MIPI_CSI1_LANE0_P DEBUG CONNECTOR CAMERA MIPI_CSI1_LANE0_N MIPI_CSI1_CLK_P Disable internal PM_VIB_DRV_N Charging MIPI_CSI1_CLK_N OPT1 VREG_L12_2P95V MIC3_IN_P VBUS_USBIN R=0Ω MIC2_IN_P VPH_PWR CDC_HS_DET VCHG VPH_PWR SPKR_DRV_M VCOIN PMIC_INT VPH_PWR SPKR_DRV_P VREG_L17_2P85V CDC_EARO_M... -
Page 9: Terms And Acronyms
SHANGHAI SIMCOM LIMITED Terms and acronyms Table1-2 Terms and acronyms Term Definition Analog-to-digital converter Automatic gain control Adaptive voltage scaling Bit error rate BNSP Bare nanoscale packaging Bits per second Bluetooth Carrier aggregation CDMA Code division multiple access Cyclic redundancy code... - Page 10 SHANGHAI SIMCOM LIMITED Table1-2 Terms and acronyms (cont.) Term Definition HSUPA High-speed uplink packet access Inter-integrated circuit Inter-IC sound Image signal processing JTAG Joint Test Action Group (ANSI/ICEEE Std. 1149.1-1990) kbps kilobits per second Liquid crystal display Low-power audio LPASS...
- Page 11 SHANGHAI SIMCOM LIMITED Table1-2 Terms and acronyms (cont.) Term Definition SPMI System power management interface Symbols per second (or samples per second) SPSS Smart peripheral subsystem SSBI Single-wire SBI Static voltage scaling Test access port To be discussed TCXO Temperature-compensated crystal oscillator...
-
Page 12: Interface Definitions
SHANGHAI SIMCOM LIMITED 2 Interface Definitions _______________________________________________________________________________ 2.1 Interface configuration Figure2-1 Interface configuration... -
Page 13: Pin Definitions
SHANGHAI SIMCOM LIMITED 2.2 Pin definitions Table2-1 SIMT1502 Pin definitions Pad characteristics Default Pin# Pad name GPIO Functional description Type Configurable I/O; SCAM_RST_N SCAM_RST_N GPIO_28 B-PD:nppukp Sub Camera reset Configurable I/O; SCAM_MCLK SCAM_MCLK GPIO_27 B-PD:nppukp Sub camera clock MIPI camera serial interface1... - Page 14 SHANGHAI SIMCOM LIMITED Configurable I/O; SE955_TRIGGER UART2_CTS_N/SCL GPIO_ /N5600_ILL B-PD:nppukp UART, SPI or I2C BLSP#2 WIFI_BT_RF WIFI_BT_RF 2.4G WIFI signal Configurable I/O; TS_IN_N TS_IN_N GPIO_13 B-PD:nppukp Touch screen interrupt Configurable I/O; TS_I2C_SDA TS_I2C_SDA GPIO_18 B-PD:nppukp Touch screen I2C Configurable I/O;...
- Page 15 SHANGHAI SIMCOM LIMITED Camera I2C SDA (only) GPIO_29 CAM_I2C_SDA GPIO_29 B-PD:nppukp Camera I2C SCL (only) GPIO_30 CAM_I2C_SCL GPIO_30 B-PD:nppukp Configurable I/O; UIM2_PRESENT KYPD_EN GPIO_52 B-PD:nppukp Power on key (only) PM_KYPD_PWR_N PM_KYPD_PWR_N PMU CTR Vibration motor PM_VIB_DRV_N PM_VIB_DRV_N PMU CTR driver output control...
- Page 16 SHANGHAI SIMCOM LIMITED MIPI display serial interface 0 AI, AO MIPI_DSI0_ LANE1_P MIPI_DSI0_ LANE1_P lane 1 – positive MIPI display serial interface 0 AI, AO MIPI_DSI0_ LANE1_M MIPI_DSI0_ LANE1_M lane 1 – negative MIPI MIPI display serial interface 0 AI, AO...
- Page 17 SHANGHAI SIMCOM LIMITED Configurable I/O GPIO_93 OTG_EN GPIO_93 BB-PD:nppukp Configurable I/O GPIO_94 ALSP_INT_N GPIO_94 BB-PD:nppukp Configurable I/O GPIO_95 CHG_EN GPIO_95 BB-PD:nppukp Configurable I/O GPIO_96 VBUS_OTG_EN GPIO_96 BB-PD:nppukp Configurable I/O GPIO_97 NFC_DWL_REQ GPIO_97 B-PD:nppukp GPIO_110 NFC_INT_N Configurable I/O GPIO_ B-PD:nppukp Configurable I/O...
-
Page 18: Electrical Specifications
SHANGHAI SIMCOM LIMITED 3 Electrical Specifications _______________________________________________________________________________ 3.1 Operating conditions 1.8 V digital I/O characteristics 1.8 V digital I/O characteristics ( ( ( ( P3) ) ) ) : : : : 1.8 V digital I/O characteristics 1.8 V digital I/O characteristics VDD_P3 GPIOs Dual- - - - voltage 1.8 V/2.95 V digital I/O characteristics... -
Page 19: Current Test Report
SHANGHAI SIMCOM LIMITED 3.2 Current test report This Current test report based on the EVB board, V =3.8V. All values are typical unless otherwise specified. 1. During suspend (Airplane mode, no UIM, system in sleep mode): 2.9mA. 2. During suspend (WIFI wake up, BT off, system in sleep mode): 3.0mA. -
Page 20: Application Interface Specifications
SHANGHAI SIMCOM LIMITED 4 Application Interface Specifications _______________________________________________________________________________ 4.1 Power interface The power supply of SIMT1502 comes from PM8909. See Table4-1 Table4-1 Power source description Direction Voltage(V) Current(mA) Signal Pin# PI/PO VREG_L11_2P95V 1.75 2.95 3.337 VREG_L12_2P95V 1.75 1.8/2.95 3.337 VREG_L17_2P85V 1.75... -
Page 21: Usb Interface
SHANGHAI SIMCOM LIMITED 4.3 USB interface SIMT1502 contains a USB interface which support On-The-Go. It is compliant with the USB2.0 specification. The USB2.0 specification requires hosts to support all three USB speeds, low-speed (1.5Mbps), full-speed (12Mbps) and high-speed (480Mbps). See Table4-3 and Figure4-1 for more details. -
Page 22: Camera Interface
SHANGHAI SIMCOM LIMITED Table4-4 Audio interface description Direction Signal Pin# Description AI/AO MIC3_IN Microphone 3 input, single-ended MIC2_IN Microphone 2 input, single-ended HS_DET Headset detection SPKR_DRV_M Speaker driver output, minus SPKR_DRV_P Speaker driver output, plus EARO_M Earpiece amplifier output, differential minus... - Page 23 SHANGHAI SIMCOM LIMITED MIPI_CSI1_CLK_P MIPI camera serial interface 1 clock – positive MIPI_CSI1_CLK_N MIPI camera serial interface 1 clock – negative CAM_PWDN Camera0 PWDN CAM_I2C_SDA Camera I2C,SDA CAM_I2C_SCL Camera I2C,SCL CAM1_RST_N Camera 1 (rear camera) reset CAM1_STANDBY_N Camera 1 (rear camera) standby MIPI_CSI0_LN1_N MIPI camera serial interface 0 clock –...
-
Page 24: Display Interface
SHANGHAI SIMCOM LIMITED 4.6 Display interface SIMT1502 contains one display interface. The interface use MIPI display serial interface, support up to four lanes. Support for the resolution of WVGA, qHD and 720p LCM.. The backlight circuit is not contained in SIMT1502, which must be designed in external circuit. -
Page 25: Ctp Interface
SHANGHAI SIMCOM LIMITED 4.7 CTP interface SIMT1502 contains one CTP interface, the panel is controlled by I2C bus. See Table4-7 and Figure4-5 for more details. Table4-7 CTP interface description Direction Signal Pin# Description AI/AO TS_INT_N Touchscreen interrupt TS_I2C_SDA Touchscreen I2C,SDA... -
Page 26: Sensors Interface
SHANGHAI SIMCOM LIMITED Figure4-6 SD interface application diagram 4.9 Sensors interface SIMT1502 support many sensors via I2C bus, the circuit structure is similar to camera interface. SIMT1502 does not contain necessary pull_up resistors internal, which must be designed in external circuit. -
Page 27: I2C , Uart And Spi Interface
SHANGHAI SIMCOM LIMITED SIMT1502 must be provided voltage by external voltage source. See Table4-10 for more details. Table4-10 Battery connector description Direction Signal Pin# Description AI/AO BAT_THERM Battery therm monitor VBATT 88/92/124(No External Charging IC) Battery positive supply VBATT 88 (With External Charging IC) -
Page 28: I2C
SHANGHAI SIMCOM LIMITED 4.12.2 I2C SIMT1502 contains two groups special functional and four groups configurable I2C, which multiplexed with UART function. I2C pins use GPIOs configured as open-drain outputs; the pull-up resistor(2.2K) must be provided by external circuit(1.8V). High speed mode I2C running at 3.4 MHz. -
Page 29: Other Interface
SHANGHAI SIMCOM LIMITED Direction Signal Pin# Description GPIO_4 SPI1 MOSI GPIO_5 SPI1 MISO GPIO_6 SPI1 CS_N GPIO_7 SPI1 CLK GPIO_20 SPI2 MOSI GPIO_21 SPI2 MISO GPIO_111 SPI2 CS_N GPIO_112 SPI2 CLK GPIO_0 SPI3 MOSI GPIO_1 SPI3 MISO GPIO_2 SPI3 CS_N... -
Page 30: Rf Signal Input Port
SHANGHAI SIMCOM LIMITED VCOIN Sense input or charge output AI,AO 4.13.4 RF Signal input port SIMT1502 contains four RF signal input port: BT/WIFI. See Table4-16 and Figure4-8 for more details: Table4-17 RF Signal input port Direction Signal Pin# Description RF_IN_2... -
Page 31: Mechanical Specification
SHANGHAI SIMCOM LIMITED 5 Mechanical Specification _______________________________________________________________________________ 5.1 Overview This specification defines a small form factor module for systems in which a Stamp hole package add-in module can not be used due to mechanical system design constraints. The specification defines a smaller module based on a single 124-pin Leadless Chip Carriers encapsulation for system interfaces by card edge type. -
Page 32: Simt1502 Pcb Details
SHANGHAI SIMCOM LIMITED 5.2.2 SIMT1502 PCB details The following figures (Figure5-2) provide the printed circuit board (PCB) details required to fabricate the PCB. The PCB for this application is expected to be 1.2 mm thick. The steel net thickness is 0.12mm (Figure5-3). -
Page 33: System Btb Connector Specifications
SHANGHAI SIMCOM LIMITED 5.3 System BTB connector specifications The SIMT1502 have a BTB connector In order to more GPIO interface 5.3.1 BTB connector The BTB connector is 30-pin card edge type connector. Detailed dimensions should be obtained from the connector manufacturer. Figure5-4 shows the BTB connector. We use AXE530127 as socket and AXE630127 as header. -
Page 34: Rf Specification
SHANGHAI SIMCOM LIMITED 6 RF Specification _______________________________________________________________________________ 6.1 R&D parameters All measurements are taken at module RF I/O pins (pin 31 for BT/WIFI and RF connector for 5G_WIFI) with IQ2015. All typical performance specifications are based on operation at room temperature (+25°C) using default parameter settings and nominal supply voltages, such as VBAT = 3.8V. - Page 35 SHANGHAI SIMCOM LIMITED CHAN2 2417 CHAN3 2422 CHAN4 2427 CHAN5 2432 CHAN6 2437 CHAN7 2442 CHAN8 2447 CHAN9 2452 CHAN10 2457 CHAN11 2462 CHAN12 2467 CHAN13 2472 Table6-4 5G WiFi channels 20MHz 40MHz Channel Frequency Channel Frequency CHAN36 5180 CHAN38...
-
Page 36: Simt1502 Wifi Transmission Type And Supported Modulation
SHANGHAI SIMCOM LIMITED Data Rate(Mbps) Modulation Format 1Mbps(DSSS) DBPSK 2Mbps(DSSS) DQPSK 802.11B 5.5Mbps(CCK) DQPSK 11Mbps(CCK) DQPSK 6Mbps(OFDM) BPSK 9Mbps(OFDM) BPSK 12Mbps(OFDM) QPSK 18Mbps(OFDM) QPSK 802.11A / G 24Mbps(OFDM) 16QAM 36Mbps(OFDM) 16QAM 48Mbps(OFDM) 64QAM 54Mbps(OFDM) 64QAM 6.5Mbps(MCS0) BPSK 13Mbps(MCS1) QPSK 19.5Mbps(MCS2) QPSK 802.11N... - Page 37 SHANGHAI SIMCOM LIMITED...
-
Page 38: Declaration Of Conformity (Doc)
SHANGHAI SIMCOM LIMITED Declaration of Conformity (DoC) is in conformity with the relevant Union harmonization legislation: Radio Equipment directive: 2014 / 53 / EU with reference to the following standards applied: EN 301 489-1 V2.2.0 (2017-03); EN 301 489-17 V3.2.0 (2017-03)
