SimCom SIM5320AL User Manual page 16

Table 2: Pin definition
Pin No. Define
1 GND
3 POWER_ON
5 GND
7 SPI_MISO_DATA
9 SPI_CS_N
11 USB_VBUS
13 USB_DP
15 RESERVED
17 USIM_DATA
19 USIM_CLK
21 NC
NC
23
25 NC
27 KEYSENSE_N1
29 KEYPAD_0
31 KEYSENSE_N2
33 KEYPAD_1
35 KEYPAD_3
37 GND
39 VBAT_BB
41 GND
43 GND
45 CURRENT_SINK
47 ADC1
49 GPIO40
51 GPIO1
53 GPIO42
55 I2C_SCL
57 GND
59 MAIN_ANT
61 GND
63 VBAT_RF
65 GND
SIM5320AL_User Manual_V1.01
Pin No. Define
2 GND
4 RESET
6 SPI_CLK
8 SPI_MOSI_DATA
10 GND
12 USB_DM
14 GND
16 RESERVED
18 USIM_RESET
20 V_USIM
22 NC
NC
24
26 NC
28 KEYSENSE_N0
30 KEYPAD_2
32 KEYSENSE_N3
34 KEYPAD_4
36 KEYSENSE_N4
38 VBAT_BB
40 GND
42 VRTC
44 VREG_AUX
46 ADC2
48 GPIO44
50 GPIO43
52 GPIO41
54 GPIO4
56 I2C_SDA
58 GND
60 GND
62 VBAT_RF
64 GND
66 UART_RTS
16
