of errors exceeds the low threshold configured, a link event notification OAMPDU packet is sent together with a sym-
bol-period event TLV. If an action has been configured through high-threshold-action and the high threshold is sur-
passed, said action is executed.
Syntax:
ethernet0/1 OAM config>link-monitor symbol-period ?
high-threshold
low-threshold
window
ethernet0/1 OAM config>link-monitor symbol-period high-threshold ?
high-threshold
ethernet0/1 OAM config>link-monitor symbol-period low-threshold ?
<1..65535>
ethernet0/1 OAM config>link-monitor symbol-period window ?
<500..65535>
Example:
ethernet0/1 OAM config>link-monitor symbol-period low-threshold 10
ethernet0/1 OAM config>
9.3.3 NO
Recovers default values for each of the configurable OAM parameters and disables certain functions (OAM protocol,
loopback mode, link monitoring, etc.).
Syntax:
ethernet0/1 OAM config>no ?
link-monitor

oam

remote-failure
remote-loopback
Example:
ethernet0/1 OAM config>no link-monitor enable
ethernet0/1 OAM config>
9.3.4 OAM
Enables the OAM functionality and configures various global parameters that control protocol operation. The follow-
ing parameters are available (amongst others):
Syntax:
ethernet0/1 OAM config>oam ?
enable
max-rate
min-rate
mode
timeout
Subsequent sections describe each of the configurable parameters.
9.3.4.1 OAM ENABLE
Enables the OAM functionality in the Ethernet interface that is being configured. Default is disabled.
Syntax:
ethernet0/1 OAM config>oam enable ?
<cr>
Example:
ethernet0/1 OAM config>oam enable
ethernet0/1 OAM config>
LAN Interfaces
Set high-threshold value
Set low-threshold value
Set window value
Set high-threshold value (number of symbols)
Set low-threshold value (number of symbols)
Set window value (millions of symbols)
Link monitor OAM configuration
General OAM configuration
Remote-failure OAM configuration
Remote-loopback OAM configuration
Enable Ethernet OAM functionality
Set the maximum rate for OAMPDUs transmitted
Set the minimum rate for OAMPDUs transmitted
Set the OAM Client mode
Set the OAM Discovery FSM timeout
