Example:
token-ring3/0 config>?

list

llc

mac-address
no
packet-size
rif-timer
source-routing
speed
exit
token-ring3/0 config>
1.3.2 LIST
Displays the current configuration for the Token Ring interface.
Syntax:
token-ringX/X config>list
Example:
token-ring3/0 config>list
Packet size :
Speed:
RIF aging:
Source Routing: Enabled

MAC address:

token-ring3/0 config>
1.3.3 LLC
Accesses the LLC configuration. This configuration is mandatory to forward packets over the SNA network. See the
LLC Configuration Commands section for a description of the available commands and their use.
Syntax:
token-ringX/X config>llc
Example:
token-ring3/0 config>llc
-- LLC User Configuration --
token-ring3/0 LLC config>
1.3.4 MAC ADDRESS
Configures the physical address of the interface (MAC). The interface can adopt locally administered addresses, or
those given by the device manufacturer (universal administration). Through this command, only locally administrated
addresses are deemed valid. Entering 00:00:00:00:00:00 (default value) forces the router to use the address given
by the manufacturer for the interface. This last MAC address is used by default.
Example:
token-ring3/0 config>mac-address 50:84:c0:4c:84:4e
token-ring3/0 config>
1.3.5 NO
Sets the different parameters to their default values.
Syntax:
token-ringX/X config>no ?
mac-address
packet-size
LAN Interfaces
List configuration
Enter the LLC configuration menu
Configure the interface physical address
Negate a command or set its defaults
Change packet size for all Token Ring networks
Configure the RIF timer
Enable or disable end station source routing
Modify the data transmission speed
2052
16 Mbps
120
00:00:00:00:00:00
Restore universal administration MAC
Set default packet size (2052 bytes)
1 Configuring Token Ring Interfaces
3
