2 Monitoring Token Ring Interfaces

Chapter 2 Monitoring Token Ring Interfaces

2.1 Introduction

This chapter describes the monitoring of Token Ring interfaces and includes the following sections:

• Accessing Token Ring Monitoring.

• Token Ring Monitoring Commands.

• Token Ring Interfaces and the Monitoring Interface Command.
2.2 Accessing Token Ring Monitoring
To access Token Ring Monitoring:
(1) Enter device at the monitoring menu (+) to display the list of interfaces configured in the router.
(2) Enter network, followed by the Token Ring interface name, at the monitoring menu (+).
Example:
*monitor
Console Operator
+device
Interface
ethernet0/0
serial0/0
serial0/1
serial0/2
bri0/0
x25-node
token-ring3/0
+network token-ring3/0
-- Token Ring Console --
token-ring3/0 TKR+
2.3 Token Ring Monitoring Commands
The following table summarizes the Token Ring monitoring commands, further explained in the subsequent sections.
Enter these commands from the Token Ring monitoring menu.
Command

? (HELP)

LLC
RIF-DUMP
EXIT
2.3.1 ? (HELP)
Shows the available commands or their options.
Syntax:
token-ringX/X TKR+?
Example:
token-ring3/0 TKR+?
LLC
RIF-DUMP
EXIT
token-ring3/0 TKR+
6
Auto-test
CSR Vect valids
FA200e00 27
FA200a00 5e
FA200a20 5d
FA200a60 5b
FA200a40 5c
0 0
E0000000 24
Function
Shows available commands or their options.
Accesses the LLC monitoring menu.
Displays an RIF cache dump.
Exits the Token Ring monitoring menu.
Access to the LLC monitoring prompt
Dumps RIF information
Auto-test Maintenance
failures failures
0 2687
1 0
0 36796
0 36796
1 0
1 0
1 0
0
0
0
0
0
0
0
