8.3.4.18 LIST STP CONFIGURATION
Displays information on the Spanning Tree protocol.
Example:
ethernet0/0 Switch+list stp 1 configuration
Bridge ID (prio/add):
Vlan:
Maximum age:
Hello time:
Forward delay:
Transmit Hold Count:
Migrate Time:
Port Interface
1 ethernet0/0
2 ethernet0/0
ethernet0/0 Switch+
Bridge ID (prio/add)
VlanID
Maximum age
Hello Time
Forward Delay
Transmit Hold Count
Migrate Time
Port
Interface
Priority
Cost
State
8.3.4.19 LIST STP COUNTERS
Displays the counters associated to the Spanning Tree protocol.
Example:
ethernet0/0 Switch+list stp 1 counters
BPDUs received:
Dropped:
Errs:
Config:
TCN:
RST:
BPDUs sent:
Dropped:
Errs:
Config:
TCN:
RST:
Port Interface
---- ----------------
LAN Interfaces
28672/00-a0-26-44-03-38
100
20.000 seconds
2.000 seconds
15.000 seconds
6
3 seconds
Priority Cost
128 2000000
128 200000
Bridge identifier. Bridge priority and MAC address are displayed.
Parameter value for the bridge Vlan ID if PVST is configured for this instance.
Parameter value for the maximum age used by the Spanning Tree protocol. This
indicates the maximum time the information received in a BPDU is valid.
Parameter value for the Hello Time used by the Spanning Tree protocol. Indicates
how often the Hello BPDUs are sent.
Parameter value for the Forward Delay used by the Spanning Tree protocol. Indic-
ates the wait time in the Learning state before passing to a Forwarding state.
Parameter value for the Transmit Hold Count used by the Spanning Tree protocol.
Indicates the maximum number of BPDUs that can be sent by a port in one
second.
Parameter value for the Migrate Time used by the Spanning Tree protocol. This
parameter is used to initiate the counters that control whether Rapid Spanning
Tree BPDUs or Spanning Tree should be used, and if a port can be considered as
a port directly connected to a station (edge-port).
Port identifier.
Interface associated to the port.
Port priority.
Cost associated to the port in the Spanning Tree.
Port state: active or not.
0
0
0
0
0
0
30
0
0
0
0
30
BPDUs rcv
-------------------------------------------------------
Total Drop
State
Enabled
Enabled
Err TCN Conf RST
