6.3.3 LIST

Displays information on the interface, the service access point (SAP) and the session.
Syntax:
<interface name> LLC+list ?
interface
sap
session
<interface name> LLC+
6.3.3.1 LIST INTERFACE
Displays all SAPs opened on this interface.
Syntax:
<interface name> LLC+list interface
Example:
ethernet0/0 LLC+list interface
SAP Number of Sessions
0 0
4 1
8 0
c 0
f0 0
ethernet0/0 LLC+
6.3.3.2 LIST SAP
Displays information on the interface's specified SAP.
Syntax:
<interface name> LLC+list sap <SAP number>
Example:
ethernet0/0 LLC+list sap 4
Interface:
Reply Timer(T1):
Receive ACK Timer(T2):
Inactivity Timer(Ti):
MAX Retry Value(N2):
MAX I-Field Size(N1):
Rcvd I-frames before Ack(N3):
Transmit Window Size(Tw):
Acks Needed to Inc Ww(Nw):
Frame Type
UI-frames:
TEST-frames:
XID-frames:
I-frames:
RR-frames:
RNR-frames:
REJ-frames:
SABME-frames:
UA-frames:
DISC-frames:
DM-frames:
FRMR-frames:
I-frames Discarded by LLC:
I-frames Refused by LLC user:
LAN Interfaces
Displays all SAPs opened on the interface
Displays detailed information on a SAP
Displays detailed information on a LLC session
6,TKR/0
1 sec
1 100milisec (note: not used when N3=1)
30 sec
8
0
1
2
1
Xmt Rcvd
0 0
0 24
0 58
16 17
687 677
2 0
0 0
0 2
2 1
1 0
0 0
0 0
0
0
6 LLC Monitoring
