Chapter 4 Monitoring Ethernet Interfaces

4.1 Introduction

This chapter describes the commands used to monitor Ethernet interfaces. It includes the following sections:

• Accessing the Ethernet Monitoring Menu.

• Ethernet Monitoring Commands.

• Ethernet Interfaces and the Interface Monitoring Command.
4.2 Accessing the Ethernet Monitoring Menu
To access the Ethernet monitoring menu:
(1) Enter device at the monitoring (+) prompt to display a list of all interfaces configured on the router.
(2) Enter network, followed by the Ethernet interface identifier, at the monitoring (+) prompt.
Example:
*monitor
Console Operator
+device
Interface
ethernet0/0
serial0/0
serial0/1
serial0/2
bri0/0
x25-node
ethernet3/0
+network ethernet0/0
-- Ethernet Console
ethernet0/0 ETH+
4.3 Ethernet Monitoring Commands
The following table summarizes the Ethernet monitoring commands that are available, further explained in the sec-
tions below. Enter commands from the Ethernet monitoring menu.
Note
Not all commands specified in this section are available for all Ethernet interfaces. Depending on the
device, or on the monitoring interface, some commands may not appear.
Command
? (HELP)
BITRATE
COLLISION
COUNTERS
DOT1X
LASER
LLC
OAM
POWER-
SOURCING-EQUIPMENT
REGISTERS
LAN Interfaces
Auto-test
CSR Vect valids
FA200E00 27
FA200A00 5e
FA200A20 5d
FA200A60 5b
FA200A40 5c
0 0
F2000000 22
--
Function
Displays available commands or their options.
Measures the real transmission and reception rate in Ethernet.
Displays collision statistics for a specified Ethernet interface.
Displays different statistics for an interface.
Accesses the authentication 802.1X monitoring menu.
Displays information on the laser used.
Accesses the LLC monitoring menu.
Accesses the OAM protocol monitoring menu.
Accesses the Power Over Ethernet monitoring menu.
Displays the content of the controller registers.
Auto-test Maintenance
failures failures
1 0
0 2596
0 2596
0 2596
1 0
1 0
1 1

4 Monitoring Ethernet Interfaces

0
0
0
0
0
0
0
19
