8 Switch Monitoring
Release
11.01.05
8.3.4.13 LIST STATS
Displays statistics on a switch port.
Syntax:
ethernetX/X Switch+list stats <port identifier>
Example 1:
ethernet3/0 Switch+list stats 4
Port: 4
-------
rx_lo_priority_byte .............. 229330857
rx_hi_priority_byte .............. 0
rx_undersize_pkt ................. 0
rx_fragments ..................... 0
rx_oversize ...................... 0
rx_jabbers ....................... 0
rx_symbol_error .................. 0
rx_crc_error ..................... 1
rx_alignment_error ............... 0
rx_control_8808_pkts ............. 0
rx_pause_pkts .................... 0
rx_broadcast ..................... 205113
rx_multicast ..................... 1134065
rx_unicast ....................... 409052
rx_64_octets ..................... 180378
rx_65_to_127_octets .............. 1448751
rx_128_to_255_octets ............. 10724
rx_256_to_511_octets ............. 13615
rx_512_to_1023_octets ............ 4718
rx_1024_to_1522_octets ........... 90348
tx_lo_priority_byte .............. 65313
tx_hi_priority_byte .............. 0
tx_late_collision ................ 0
tx_pause_pkts .................... 0
tx_broadcast ..................... 84
tx_multicast ..................... 569
tx_unicast ....................... 251
tx_deferred ...................... 7
tx_total_collision ............... 10261
tx_excessive_collision ........... 629
tx_single_collision .............. 150
tx_multiple_collision ............ 12
tx_drop_packets .................. 0
rx_drop_packets .................. 0
Info_last_change ................. 1175
ethernet3/0 Switch+
The meaning of the fields is as follows:
rx_lo_priority_byte:
rx_hi_priority_byte:
rx_undersize_pkt:
rx_fragments:
rx_oversize:
rx_jabbers:
rx_symbol_error:
rx_crc_error:
rx_alignment_error:
rx_control_8808_pkts:
76
Modification
The "FC", "Pause" and "Asym" options have been introduced as of version 11.01.05.
Bytes received with low priority, including packets with errors.
Bytes received with high priority, including packets with errors.
Undersized packets received with correct CRC.
Fragments received with CRC, alignment or symbol errors.
Oversized packets received with correct CRC.
Oversized packets received with CRC, alignment or symbol errors.
Packets received with symbol error and admitted size.
Packets received with CRC error.
Packets received with alignment error.
Control packets received (EtherType=0x8808).
