set Set device register
Note
If no options are available, command registers will display all controller registers.
4.3.10.1 REGISTERS GET
Displays the value of a given register.
Syntax:
ethernetX/X ETH+registers get
Example:
Read register at address 0x0.
ethernet2/0 ETH+registers get
Hex Register: [0]? 0
Value read: 0x08101a41
Command history:
Release
11.00.06
11.01.02
4.3.10.2 REGISTERS LIST
Displays all registers.
Syntax:
ethernetX/X ETH+registers list
Example:
ethernetX/X ETH+registers list
-General Command and Status Registers
TSEC_ID,Controller ID
TSEC_ID2,Controller ID
IEVENT,Interrupt Event
IMASK,Interrupt Mask
EDIS,Error Disabled
ECNTRL,Ethernet Control
PTV,Pause Time Value
DMACTRL,DMA Control
TBIPA,TBI Physical Address
-FIFO Control and Status Registers
FIFO_RX_PAUSE,FIFO Receive Pause Start Threshold
FIFO_RX_PAUSE_SH,FIFO Receive Pause Shut-off Threshold
FIFO_RX_ALARM,FIFO Receive Alarm Start Threshold
FIFO_RX_ALARM_SH,FIFO Receive Alarm Shut-off Threshold
FIFO_TX_THR,FIFO Transmit Threshold
FIFO_TX_STRV,FIFO Transmit Starve
FIFO_TX_STRV_SH,FIFO Transmit Starve Shutoff
more? n
ethernet0/0 ETH+
Command history:
Release
11.00.06
11.01.02
LAN Interfaces
Modification
The "Registers Get" command was introduced as of version 11.00.06.
The "Registers Get" command was introduced as of version 11.01.02.
0x01240000
0x00300000
0x02000700
0x00000000
0x00000000
0x00003000
0x00000000
0x00000018
0x00000001
Modification
The "Registers List" command was introduced as of version 11.00.06.
The "Registers List" command was introduced as of version 11.01.02.
0x00000080
0x000000c0
0x00000040
0x00000080
0x00000080
0x00000040
0x00000080
