8 Switch Monitoring
Designated priority vector:
Designated times:
Message priority vector:
Message times:
Timers:
Machine State Status:
more ? n
ethernet0/0 Switch+
8.3.4.21 LIST STP STATE
Displays information on the current state of the Spanning Tree protocol.
Example:
ethernet0/0 Switch+list stp 1 state
Designated root (prio/add):
Vlan:
Root cost:
Root port:
Current (root) Maximum Age:
Current (root) Hello Time:
Current (root) Forward Delay:
Port Interface
1 ethernet0/0
2 ethernet0/0
ethernet0/0 Switch+
84
Max Age ................... 20.000
Hello Time ................ 2.000
Forward Delay ............. 15.000
RootBridgeID .............. 32768/00-a0-26-44-03-38
RootPathCost .............. 0
DesignatedBridgeId ........ 32768/00-a0-26-44-03-38
DesignatedPortID .......... 32769 (128/1)
BridgePortID .............. 0 (0/0)
Message Age ............... 0.000
Max Age ................... 20.000
Hello Time ................ 2.000
Forward Delay ............. 15.000
RootBridgeID .............. 32768/00-17-0e-82-e6-c2
RootPathCost .............. 0
DesignatedBridgeId ........ 32768/00-17-0e-82-e6-c2
DesignatedPortID .......... 32769 (128/1)
BridgePortID .............. 32769 (128/1)
Message Age ............... 0.000
Max Age ................... 20.000
Hello Time ................ 2.000
Forward Delay ............. 15.000
edgeDelayWhile ............ 0
fdWhile ................... 0
helloWhen ................. 1
mdelayWhile ............... 0
rbWhile ................... 0
rcvdInfoWhile ............. 0
rrWhile ................... 0
tcWhile ................... 0
Receive State Machine .............. RECEIVE
Receive State Machine .............. RECEIVE
Transmit State Machine ............. IDLE
Protocol Migration State Machine ... SENSING
Bridge Detection State Machine ..... NOT_EDGE
Port Information State Machine ..... CURRENT
Role Transitions State Machine ..... DESIGNATED_PORT
State Transition State Machine ..... FORWARDING
Topology Change State Machine ...... ACTIVE
32768/00-a0-26-44-03-38
100
0
1 (ethernet0/0)
20.000 seconds
2.000 seconds
15.000 seconds
State Role
Forwarding Designated
Forwarding Designated
