8 Switch Monitoring
Learned addresses 0
Port: 4
-------
Discarded packets MAC out of limits 0
Learned addresses 0
Ethernet0/0 Switch+
Discarded packets MAC out of limits : Number of discarded packets in a switch port from a MAC that hasn't been
learned (i.e., the maximum value specified in the configuration has been reached).
Learned addresses: number of entries learned in the port. Entries that are not in the permitted list are the only ones
counted. Using this option only makes sense when the port has a maximum of learned entries configured. It also dis-
plays the entry MACs learned.
8.3.4.2 LIST CONFIGURATION STP
Displays the ports configuration on the Spanning Tree protocol.
Syntax:
ethernetX/X Switch+list configuration stp
Example:
ethernet1/0 Switch+list configuration stp
Port Tx
---- ---- ----
1 Yes
2 Yes
3 Yes
4 Yes
5 Yes
ethernet1/0 Switch+
The following is listed for each switch port: if transmission is permitted, if reception is permitted and if MAC address
learning is permitted.
8.3.4.3 LIST CONFIGURATION VLAN
Displays the configuration for VLANs in the switch ports.
Syntax:
ethernetX/X Switch+list configuration vlan
Example:
ethernet1/0 Switch+list configuration vlan
802.1Q VLAN:
Special TPID:
Tag
Port Insertion
---- ---------
1 No
2 No
3 No
4 No
5 No
ethernet1/0 Switch+
The following fields are displayed:
802.1Q VLAN
Special TPID
Tag insertion
Tag removal
Membership
68
Rx Learning
--------
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Disabled
Disabled
Tag
Removal Membership PVID
------- ---------- ----
No 0x1f 1
No 0x1f 1
No 0x1f 1
No 0x1f 1
No 0x1f 1
Indicates whether the treatment of VLANs is enabled in the switch.
Indicates whether the special tag is enabled in the switch (characteristic used for
the Spanning Tree to work).
Indicates whether the frames are tagged when they exit through the port.
Indicates whether the tags are removed from the frames when they exit through
the port.
VLAN Port mapping. Indicates the ones a certain port can communicate with.
Ingress Filter Discard Non PVID
-------------- ----------------
No No
No No
No No
No No
No No
