1 Configuring Token Ring Interfaces

Chapter 1 Configuring Token Ring Interfaces

1.1 Introduction

This chapter describes the Token Ring interface configuration. It includes the following sections:

• Accessing the Token Ring Configuration.

• Token Ring Configuration Commands.

1.2 Accessing the Token Ring Configuration
To access the Token Ring configuration:
(1) Enter list devices at the Config> prompt to display the list of interfaces and their interface number.
(2) Enter network, followed by the Token Ring interface name.
Example:
*config
Config>list devices
Interface
ethernet0/0
serial0/0
serial0/1
serial0/2
bri0/0
x25-node
token-ring3/0
Config>network token-ring3/0
-- Token Ring User Configuration --
token-ring3/0 config>
1.3 Token Ring Configuration Commands
Certain commands are common to all device interfaces. These commands are described in Teldat Dm772-I Com-
mon Configuration Interfaces.
The following table summarizes the Token Ring configuration commands, further explained below. Enter said com-
mands from the Token Ring configuration menu.
Command

? (HELP)

LIST
LLC
MAC-ADDRESS
NO
PACKET-SIZE
RIF-TIMER
SOURCE-ROUTING
SPEED
EXIT
1.3.1 ? (HELP)
Displays the available commands and their options.
Syntax:
token-ringX/X config>?
2
Connector Type of interface
LAN1 Fast Ethernet interface
SERIAL0/WAN1 X25
SERIAL1/WAN2 X25
SERIAL2/WAN3 X25
BRI/ISDN1 ISDN Basic Rate Int
--- Router->Node
SLOT3 Token Ring
Function
Displays available commands or their options.
Displays the selected Token Ring interface configuration.
Accesses LLC configuration.
Configures the interface's physical address (MAC).
Configures default values for the configuration parameters.
Modifies packet-size for all Token Ring networks.
Configures the Routing Information Field (RIF) timer.
Enables or disables source-routing on the interface.
Sets the interface speed in Mbps.
Exits Token Ring configuration.
