9 Ethernet OAM Configuration
9.3.4.2 OAM MAX-RATE
Configures the maximum rate of OAMPDUs transmitted per time unit (packets/s). Default is 10 packets/s.
Syntax:
ethernet0/1 OAM config>oam max-rate ?
<1..10>
Example:
ethernet0/1 OAM config>oam max-rate 4
ethernet0/1 OAM config>
9.3.4.3 OAM MIN-RATE
Configures the minimum rate of OAMPDUs transmitted per second, specifying the maximum time between transmit-
ted OAMPDUs. Default is 1 second.
Syntax:
ethernet0/1 OAM config>oam min-rate ?
<1..10>
Example:
ethernet0/1 OAM config>oam min-rate 2
ethernet0/1 OAM config>
9.3.4.4 OAM MODE
Configures the operating mode of the local OAM client. There are two possibilities: active client or passive client.
Please see the section that describes the Ethernet OAM protocol for further details on the characteristics of the two
possible operating modes. Default is active mode.
Syntax:
ethernet0/1 OAM config>oam mode ?
active
passive
Example:
ethernet0/1 OAM config>oam mode passive
ethernet0/1 OAM config>
9.3.4.5 OAM TIMEOUT
Configures the maximum wait time without receiving link maintenance OAMPDUs from the remote OAM client. Once
this has timed out, the OAM session restarts and returns to the discovery stage. Default is 10 seconds.
Syntax:
ethernet0/1 OAM config>oam timeout ?
<2..30>
Example:
ethernet0/1 OAM config>oam timeout 15
ethernet0/1 OAM config>

9.3.5 REMOTE-FAILURE

Configures the actions to be executed on receiving OAMPDU packets from the remote OAM client where some of
the flags reserved for critical events are activated. You can specify an action to be taken for each of the three pos-
sible critical events:link-fault, critical-event and dying-gasp. Currently, only one action is available: disable the inter-
face. No action is specified by default in any of the three cases.
Syntax:
ethernet0/1 OAM config>remote-failure ?
critical-event
94
Set the maximum rate for OAMPDUs transmitted
Set the minimum rate for OAMPDUs transmitted
Set active mode
Set passive mode
Timeout value (seconds)
Set action on received critical-event from remote OAM client
